Blickle 901176 BO-G 200IK Heavy-duty fixed wheel Wheel diameter: 200 mm Load capacity (max.): 1000 kg 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Load capacity at 4 km/h: 1000 kg
- Material wheel body: Robust gray cast iron
- Material run lining: Metal
- Colour run lining: Silver
- Colour wheel body: Silver gray
- Temperature resistance up to 130 °C
- Temperature resistance min -30 oC
- Coating hardness 180–220 HB
- Without a trace: No.
- Anti-static: No.
- Stainless steel: No.
- Heat-resistant: Yes
- Autoclave-compatible: No.
- Resistant to hydrolysis: No.
- Mounting type: Screw-on plate
- Accompanying steering roller: LIO-G 200IK
- Associated wheel: G 200/20IK
- Product type
Heavy-duty fixed wheel
- Wheel Ø
200 mm
- Load capacity (max.)
1000 kg
- Total height
245 mm
- Size
140 x 110 mm
- Wheel width
50 mm
- Bearing type
Ball bearing
- Material
Metal
- Factory colour
Silver
- Content
1 pc(s)
- Weight
6.535 kg
Documents & Downloads
Datasheet
Datasheet 3050739 Blickle 901176 BO-G 200IK Heavy-duty fixed wheel Wheel diameter: 200 mm Load capacity (max.): 1000 kg 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3050739 Blickle 901176 BO-G 200IK Heavy-duty fixed wheel Wheel diameter: 200 mm Load capacity (max.): 1000 kg 1 pc(s)
Description
Steel welded heavy-duty fixed roller,
Cast wheel
Housing: Series BO
• Solid steel welding construction, galvanized galvanically, blue passivated, Cr6-free
Wheel: G Series
• Robust cast iron, hardness 180–220 HB, lubricating nipple, painted, color silver
Other properties:
• Chemical resistance to many aggressive media
• For pressure-sensitive floors, observe surface pressure
• Lubrication with a lubricant adapted to the application temperature
• At a temperature of +270 °C, the load capacity is reduced by 40%
This text is machine translated.
Cast wheel
Housing: Series BO
• Solid steel welding construction, galvanized galvanically, blue passivated, Cr6-free
Wheel: G Series
• Robust cast iron, hardness 180–220 HB, lubricating nipple, painted, color silver
Other properties:
• Chemical resistance to many aggressive media
• For pressure-sensitive floors, observe surface pressure
• Lubrication with a lubricant adapted to the application temperature
• At a temperature of +270 °C, the load capacity is reduced by 40%
This text is machine translated.
