BLOCK VB 3,2/2/15 PCB mount transformer 1 x 230 V 2 x 15 V AC 3.2 VA 106 mA
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 9.24
3
6% = € 0.53
€ 8.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 9.24 / piece)
€ 9.24
plus VAT.
Only 9 Piece(s) available
Highlights & Details
EI 38/13.6 Print transformer VB 3.2 VA
- Minimum size in case of high power
- Short-circuit resistant
Technical specifications
- Output voltage
15 V AC
- Output voltage (number x voltage)
2 x 15 V AC
- Output current
106 mA
- No. of inputs
1 x
- No. of outputs
2 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
3.2 VA
- Height
30.8 mm
- Type
VB 3,2/2/15
- Content
1 pc(s)
- Test mark
C-UL-US, ENEC 10 (VDE)
- Connection
Soldering
3.2 VA
- Output voltage
2 x 15 V AA
- Insulation class
VDE=B, UL=105
- Frequency
50 - 60 Hz
- Efficiency
58 %
- RoHS-compliant
Yes
- Max. ambient temperature
+50 °C
- Test voltage
5000 V
- Weight
0.17 kg
- Product type
PCB mount transformer
Documents & Downloads
Datasheet
Datasheet 710211 BLOCK VB 3,2/2/15 PCB mount transformer 1 x 230 V 2 x 15 V AC 3.2 VA 106 mA
User & Safety Instructions
User & Safety Instructions 710211 BLOCK VB 3,2/2/15 PCB mount transformer 1 x 230 V 2 x 15 V AC 3.2 VA 106 mA
Conformity certificate
Conformity certificate 710211 BLOCK VB 3,2/2/15 PCB mount transformer 1 x 230 V 2 x 15 V AC 3.2 VA 106 mA
Description
VB Dual voltage
Primary connection assignment: pin 1 to 2
Secondary 1 pin assignment: pin 4 to 3
Pin assignment Secondary 2: Pen 6-5
Primary connection assignment: pin 1 to 2
Secondary 1 pin assignment: pin 4 to 3
Pin assignment Secondary 2: Pen 6-5
Hints
Dimensional drawing see technical data sheet.
