Image similar
Image similar
BLOCK VCM 25/1/9 PCB mount transformer 1 x 230 V 1 x 9 V AC 25 VA 2.77 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 20.16
3
5% = € 1.00
€ 19.16
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 20.16 / piece)
€ 20.16
plus VAT.
Only 7 Piece(s) available
Highlights & Details
BLOCK VCM 25/1/9 PCB mount transformer 1 x 230 V 1 x 9 V AC 25 VA 2.77 A
- to N/A
- Excellent size to power ratio
- Vacuum resin moulded (self extinguishing to UL 94 V-0)
- Mounting tabs on side of housing
Technical specifications
- Product type
PCB mount transformer
- Output voltage
9 V AC
- Output voltage (number x voltage)
1 x 9 V AC
- Output current
2.77 A
- No. of inputs
1 x
- No. of outputs
1 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
25 VA
- Type
VCM 25/1/9
- Connection
Soldering
- Frequency
50 - 60 Hz
- Weight
0.61 kg
- Content
1 pc(s)
- Insulation class
VDE=B, UL=105
- Test voltage
500 V
- Test mark
C-UL-US, ENEC 10 (VDE)
- RoHS-compliant
Yes
- Max. ambient temperature
+40 °C
- Efficiency
82 %
25 VA
- Output voltage
9 V
Documents & Downloads
Datasheet
Datasheet 710825 BLOCK VCM 25/1/9 PCB mount transformer 1 x 230 V 1 x 9 V AC 25 VA 2.77 A
User & Safety Instructions
User & Safety Instructions 710825 BLOCK VCM 25/1/9 PCB mount transformer 1 x 230 V 1 x 9 V AC 25 VA 2.77 A
Description
Connection assignment primary: Pin 1 – 2
Hints
For more technical data on BLOCK's VCM 25/1/9 PCB transformer, please see its datasheet under 'downloadable documents'.
