Image similar
Image similar
BLOCK VCM 25/2/12 PCB mount transformer 1 x 230 V 2 x 12 V AC 25 VA 1.04 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.00
3
4% = € 0.92
€ 20.08
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.00 / piece)
€ 21.00
plus VAT.
Only 5 Piece(s) available
Highlights & Details
BLOCK VCM 25/2/12 PCB mount transformer 1 x 230 V 2 x 12 V AC 25 VA 1.04 A
- to N/A
- Excellent size to power ratio
- Vacuum resin moulded (self extinguishing to UL 94 V-0)
- Mounting tabs on side of housing
Technical specifications
- Product type
PCB mount transformer
- Output voltage
12 V AC
- Output voltage (number x voltage)
2 x 12 V AC
- Output current
1.04 A
- No. of inputs
1 x
- No. of outputs
2 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
25 VA
- Type
VCM 25/2/12
- Connection
Soldering
- Frequency
50 - 60 Hz
- Weight
0.61 kg
- Content
1 pc(s)
- Insulation class
VDE=B, UL=105
- Test voltage
500 V
- Test mark
C-UL-US, ENEC 10 (VDE)
- RoHS-compliant
Yes
- Max. ambient temperature
+40 °C
- Efficiency
82 %
25 VA
- Output voltage
2 x 12 V
Documents & Downloads
Datasheet
Datasheet 710435 BLOCK VCM 25/2/12 PCB mount transformer 1 x 230 V 2 x 12 V AC 25 VA 1.04 A
User & Safety Instructions
User & Safety Instructions 710435 BLOCK VCM 25/2/12 PCB mount transformer 1 x 230 V 2 x 12 V AC 25 VA 1.04 A
Conformity certificate
Conformity certificate 710435 BLOCK VCM 25/2/12 PCB mount transformer 1 x 230 V 2 x 12 V AC 25 VA 1.04 A
Description
VCM polar square wave voltage
Primary pin assignment: Pin 1 – 2
Secondary pin assignment 1: Pin 4 - 3
Secondary pin assignment 2: Pin 6 - 5
Primary pin assignment: Pin 1 – 2
Secondary pin assignment 1: Pin 4 - 3
Secondary pin assignment 2: Pin 6 - 5
Hints
For more technical data on BLOCK's VCM 25/2/12 PCB transformer, please see its datasheet under 'downloadable documents'.
