Bolt connection terminal block RT 5-PE 3049424 Phoenix Contact
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Bolt terminal
Connection
Bolt fixings
Cross section (flexible) (max.)
6 mm²
Cross section (inflexible) (max.)
6 mm²
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 10.34 / piece)
€ 516.81
plus VAT.
14-day return policy included
Highlights & Details
Bolt connection terminal block RT 5-PE
- RT 5-PE
Technical specifications
- Packaging type
Piece
- Product type
Bolt terminal
- Features
+ PG connector
- Connection
Bolt fixings
- Cross section (flexible) (min.)
0.1 mm²
- Cross section (flexible) (max.)
6 mm²
- Cross section (inflexible) (min.)
0.1 mm²
- Cross section (inflexible) (max.)
6 mm²
- AWG (min.)
27
- AWG max.
10
- Clamp width
16.3 mm
- No. of rows
1
- Number of pins
2
- Factory colour
Green
Yellow
- Nominal current
41 A
- Nominal current - rounded value
41 A
- Manufacturer part #
3049424
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
RT 5-PE
- Dim
(L x W x H) 66 x 16.3 x 51 mm
- Width
16.3 mm
- Height
51 mm
- Length
66 mm
- Flammability rating
V0
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 716911 Bolt connection terminal block RT 5-PE 3049424 Phoenix Contact
User & Safety Instructions
User & Safety Instructions 716911 Bolt connection terminal block RT 5-PE 3049424 Phoenix Contact
Description
Ground terminal block with bolt connection, cross section: 0.1 - 6 mm², AWG: 26 - 10, width 16.3 mm, color: Green-yellow
