Bopla BoPad Display Bundle Raspberry Pi® 5 B 8 GB 4 x 2.4 GHz Display
EAN:
Part number:
Item no:
Highlights & Details
BoPad 10.1 HDMI starter kit including Raspberry Pi® 5 B (8 GB)
- 10.1" display TFT LCD 16:9
- Technology: A-SI TFT active matrix
- RGB interface
- WSVGA 1024 x (RGB) x 600 pixels
- Backlight: LED 900 cd/m²
- Operating temperature range: -10 °C to 60 °C
- Inc. Raspberry Pi® 5 B (8 GB)
Technical specifications
- Product type
SBC starter kit
- Type
Raspberry Pi® 5 B
- SoC
Broadcom BCM2712
- Processor
ARM Cortex-A76
- Processor cores (No.)
4 x
- GPU
Broadcom Video Core VII
8 GB
- Clock speed
2.4 GHz
- Memory type
DDR4
SRAM
- Operating system (Version)
w/o OS
- Memory capacity
8 GB
- Internal ports
CSI (camera)
DSI (display)
GPIO (40-pin)
- External ports
2x USB 2.0
2x USB 3.0
LAN (10/100/1000)
2x HDMI™
micro SD
USB-C® (current)
PCIe 2.0
- Wi-Fi
b/g/n/ac
- Bluetooth
5.0
- Power supply (LOV)
via USB
- Output voltage
5 V DC
- Output current
5 A
- Content
Display
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3196682 Bopla BoPad Display Bundle Raspberry Pi® 5 B 8 GB 4 x 2.4 GHz Display
Description
The BoPad starter kit has an HDMI and a USB-C connection so you can connect a multitude of devices. Possible usage area control or surveillance monitor, input monitor, machine operation, etc. Touch/display unit glued to the front screen in an "optical bonding" process.
Raspberry Pi® 5 BInc.:
Raspberry Pi® 5 B Since September 2023, he has been part of the Raspberry Pi® family. The following improvements/changes were made to the 5B:
1) The CPU has been upgraded to a 2.4 GHz ARM Cortex-A76 Quad-Core CPU (2-3x faster than its predecessor).
2) VideoCore VII graphics processor
3) 2x MIPI connectors (2x DSI/CSI)
4) 5V/5A DC power supply via USB-C™ with Power delivery support
5) New connections: PCIe 2.0 interface for e.g. SSD M.2 storage devices, on/off switch, RTC battery connection, additional UART-connection, additional fan connection
Raspberry Pi® 5 BInc.:
Raspberry Pi® 5 B Since September 2023, he has been part of the Raspberry Pi® family. The following improvements/changes were made to the 5B:
1) The CPU has been upgraded to a 2.4 GHz ARM Cortex-A76 Quad-Core CPU (2-3x faster than its predecessor).
2) VideoCore VII graphics processor
3) 2x MIPI connectors (2x DSI/CSI)
4) 5V/5A DC power supply via USB-C™ with Power delivery support
5) New connections: PCIe 2.0 interface for e.g. SSD M.2 storage devices, on/off switch, RTC battery connection, additional UART-connection, additional fan connection
Features
- Mounting dome for various development boards
- Easy to read in daylight thanks to strong backlight
- Advantages of "optical bonding" method
- No air gap
- Keeps dust and moisture out
- Better use of the touch-screen
- Higher contrast and better readability
- This text is machine translated.
Scope of delivery
- 1x BoPad 10.1 P (black, similar to 9005) including mounted 10.1" display
- 1x cable through socket (mounted)
- 6x casing screws
- 6x screw cover
- 4x Rubber feet
- 4x attachment screws for Raspberry Pi
- 1x tailor-made delivery packaging
- Original Raspberry Pi power supply
- 32 GB micro-SD card including Raspberry Pi® bookworm operating system
