Bosch 7739617393 CS7001iAW 9 ORMB Airt to water heat pump Energy efficiency rating (calc) A++ (A+++ - D)
EAN:
Part number:
Item no:
Highlights & Details
CS7001iAW 9 ORMB, external, buffer module
- Air/water heat pump crimp
Technical specifications
- Type formula: CS7001iAW 9 ORMB-S
- Class for the seasonal average of room heating energy efficiency (55°C inlet temperature): A++
- Energy efficiency classes: A+++ -> D.
- Seasonal room heating energy efficiency under average climatic conditions (55°C flow temperature): 133 %
- Rated heat output under average climatic conditions (55°C flow temperature): 7 kW
- Class for seasonal ambient heating energy efficiency (35°C lead-in temperature): A+++
- Energy efficiency classes: A+++ -> D.
- Seasonal room heating energy efficiency under average climatic conditions (35°C flow temperature): 181 %
- Rated heat output under average climatic conditions (35°C flow temperature): 8 kW
- Sound power level outdoors: 48 dB (A)
- Environmental note: Contains fluorinated greenhouse gases
- Coolant type: R410A
- Global warming potential of refrigerant (GWP): 2088 kgCO2-EQ
- Refrigerant capacity 2.35 kg
- CO2 equivalent of refrigerant capacity: 4.907 toCO2-EQ
- Cold loop design: Hermetically closed
- Heating power +7/35°C according to EN 14511: 3.8 kW
- COP +7/35°C ACCORDING TO EN 14511: 5 -
- Heating power +2 /35 °C according to EN 14511: 4.4 kW
- COP +2/35°C ACCORDING TO EN 14511: 4.3 -
- Heating power -7/35°C according to EN 14511: 6.2 kW
- COP -7/35°C ACCORDING TO EN 14511: 3.2 -
- Cooling performance in case of A35/W7 according to EN 14511: 4.9 kW
- EER at A35/W7 according to EN 14511: 2.8 -
- Air volume flow nom.: 4500 m³/h.
- Min. Outdoor air temperature -20°C
- Outdoor air temperature max. 35 °C
- Electrical connection 230 V.
- Electrical frequency 50 Hz
- 16 A fuse
- R410A refrigerant quantity: 2.35 kg
- Product type
Airt to water heat pump
- Operating voltage
230 V
- Width
930 mm
- Height
1380 mm
- Depth
440 mm
- Weight
248
A+++ (A+++ - D)
A++ (A+++ - D)
6 kWh/year
9 kWh/year
- Sound pressure level (outdoors)
48 dBa
- Sound pressure level (indoors)
49 dBa
A++ (A+++ - D)
- Factory colour
White
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2996672 Bosch 7739617393 CS7001iAW 9 ORMB Airt to water heat pump Energy efficiency rating (calc) A++ (A+++ - D)
User & Safety Instructions
User & Safety Instructions 2996672 Bosch 7739617393 CS7001iAW 9 ORMB Airt to water heat pump Energy efficiency rating (calc) A++ (A+++ - D)
Description
Air-to-water heat pump COMPRESS 7000i AW consisting of externally mounted heat pump unit and internal unit
Optimized for monoenergetic operation
This text is machine translated.
Optimized for monoenergetic operation
This text is machine translated.
Features
- Quiet and compact
- Whisper-mode possible
- Fast, simple and space-saving installation
- Easy access to the components makes it especially service friendly
- Connections at the rear
- Thermal disinfection
- Flow temperature controlled
- Energetically optimized defrosting process
- Heat pump unit consisting of: Inverter operated double roller piston compressor, large-area coated evaporator with protective grille, housing made of EPP, 2 electronic expansion valves
- Internal unit AWMB consisting of: Operating unit HPC 400, buffer storage, electric additional heater, expansion tank, 2 circulation pumps (primary and secondary circuit), 2 change-over valves (warm water and heating / VC0), safety group
Scope of delivery
- Air/water heat pump Compression - CS7001iAW 9 ORMB, external, buffer module
- 120 liter buffer memory
- Electric additional heater: 9 kW
- Expansion tank 17 l
