Bosch Home and Garden Atino Multi-line laser Self-levelling Range (max.): 1.7 m
EAN:
Part number:
Item no:
Datasheet (PDF)
Total (€ 53.77 / piece)
€ 53.77
plus VAT.
14-day return policy included
Bosch Home and Garden
Technical specifications
- Number of laser lines: 1
- Laser type 630 – 650 nm
- Leveling instructions: Laser line can be leveled at 0°, 90°, 180° and 270° by rotating the housing
- Leveling indication: LED light guide (green, yellow, red)
- Indication of leveling: Yes
- Measuring tape unit: Metric
- Accuracy of the measuring tape: +/- 2 mm/m.
- Measuring range 1.5 m
- Wall mounting type: Gel pads or pins (depending on surface)
- Use of gel pads (gel pad life): Min. Can be attached 60 times
- Working temperature: +5°C to +40°C
- Storage temperature: -20°C to +70°C.
- Product type
Multi-line laser
- Features
Self-levelling
- Range (max.)
1.7 m
- Accuracy (+/-)
3 mm
- Auto-adjustment range (+/-)
3°
- Laser category
2
- Visible beam length
1.7 m
- Operating time (battery-powered)
5 h
- Power supply (details)
1.5 V
- Length
124 mm
- Width
115 mm
- Height
62 mm
- Dim
(L x W x H) 124 x 115 x 62 mm
- Weight
260 g
- Weight, information
incl. battery
Manufacturer's standards (no certificate)
- Type (Bosch)
Bosch-do-it (green)
- Type
Atino
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2295606 Bosch Home and Garden Atino Multi-line laser Self-levelling Range (max.): 1.7 m
User & Safety Instructions
User & Safety Instructions 2295606 Bosch Home and Garden Atino Multi-line laser Self-levelling Range (max.): 1.7 m
Description
The Bosch Atino leveling laser: Mounting, aligning, measuring - Atino offers easy alignment and measurement in one operation. Atino can be attached to almost any surface at the desired place of departure by its micro-absorbent pad or the supplied pin plate. The laser line can be set manually by rotating the rotating housing. An LED traffic light system supports the alignment of the laser line to 90, 180 or 270 degrees. After desired alignment, the required markings on the surface, e.g. for drilling holes, can be marked entirely alone with the help of the integrated 1.5 m long measuring tape.
This text is machine translated.
This text is machine translated.
Features
- Manual leveling device combined with integrated measuring tape for all simple leveling and measuring tasks
- Maximum flexibility through simple, fast and flexible attachment of the tool to the wall by means of a micro-suction pad or pins
- permits leveling and measuring of distances up to 1.5m in one operation and without further support.
Scope of delivery
- 1x gel pads
- Protective cap for gel pads
- Pin pad with 2 pins
- 1X 1.5 V LR6 (AA)
- User manual.
