Bosch Professional GRL 400 H + LR 1 in L-BOXX 360-degree laser Self-levelling Range (max.): 400 m
EAN:
Part number:
Item no:
Technical specifications
- Rotation speed: 600 rpm
- 635 nm, 1mW
- Dust and splash-water protection: IP56
- Receiver LR1: Reception area: 4 cm
- Working range: Ma. 400 m
- Automatic cut-off: 10 min.
- Product type
360-degree laser
- Features
Self-levelling
- Range (max.)
400 m
- Laser category
2
- Visible beam length
635 nm
- Operating time (battery-powered)
30 h
- Power supply (details)
2 x 1.2-V-HR 20(D)(9 Ah) · 2 x 1.5 V LR20 (D)
- Length
190 mm
- Width
180 mm
- Height
170 mm
- Dim
(L x W x H) 190 x 180 x 170 mm
- Weight
1.8 kg
Manufacturer's standards (no certificate)
- Type (Bosch)
Bosch Professional (blue)
- Type
GRL 400 H + LR 1 in L-BOXX
- Type
Drill. MACHINE GRL 400 H Professional
- Reading range
(With/without receiver) Ø 400/20 m
2 kg
TRUE
TRUE
Other
Class 2
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3193073 Bosch Professional GRL 400 H + LR 1 in L-BOXX 360-degree laser Self-levelling Range (max.): 400 m
Description
Rotating laser GRL 400 H + LR 1 in L-BOXX , easy to use and always ready – the GRL 400 H rotating laser can be operated intuitively with a button, is always and immediately ready to use, when it comes to the leveling in the open. Its one-button control panel, electronic self-leveling and convenient battery compartment mean easy working with easy setup and changing the battery - without ever having to move the tool. With an accuracy of ± 2.4 mm to 30 m and a ADS shock warning function, which reports smallest changes in the position of the device, the GRL 400 H prevents leveling errors and consistently delivers precise results. From the determination of excavation and ablation values for excavation and foundations to the leveling of concrete casings up to the landscaping: This device makes its work excellent. Thanks to IP56 intrusion protection against water and dust, this rotating laser withstands the rough conditions when used outdoors. Laser receiver LR 1 Professional (0 601 015 400). L-BOXX 238 (1 600 A01 2G2). 2 x rechargeable battery 1.2V HR20 (D) Varta. 1 x rechargeable battery 9V 7HR9V Varta. 1 x Varta charger
This text is machine translated.
This text is machine translated.
Features
- Single-button-Function
- shock warning function
- Fully automatic self-levelling
- LED-display
- Dust and splash-water protection IP56
- Aluminum protective basket with glass panel.
Scope of delivery
- Receiver LR1
- Laser goggles
- alkaline batteries
- Battery Pack (NiMH)
- Magnetic target plate
- Charger
- Case.
