Stroke drawing/circuit diagram
Stroke drawing/circuit diagram
Bourns 3683S-1-103L Cermet potentiometer 2 W 10 kΩ 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Cermet potentiometer
Resistance
10 kΩ
Resistance characteristic
linear
Power rating
2 W
Datasheet (PDF)
Number
Total (€ 57.81 / piece)
€ 57.81
plus VAT.
Only 1 Piece(s) available
Highlights & Details
Cermet potentiometer, 10 speed, 10 kΩ, 2 W, solder lug, 3683S-1-103L
- 10 kΩ
- linear
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
Cermet potentiometer
- Resistance
10 kΩ
- Resistance characteristic
linear
- Power rating
2 W
- Connection
Solder tag
- Type
straight
- Length
37.1 mm
- Width
23.62 mm
- Min. temperature
-25 °C
- Max. temperature
85 °C
- Content
1 pc(s)
- Type
3683S-1-103L
- Dim
(L x W) 37.1 mm x 23.62 mm
- RoHS-compliant
Yes
- No. of rotations
10
Documents & Downloads
Datasheet
Datasheet 2996320 Bourns 3683S-1-103L Cermet potentiometer 2 W 10 kΩ 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 2996320 Bourns 3683S-1-103L Cermet potentiometer 2 W 10 kΩ 1 pc(s) Piece
Description
Digital cermet potentiometer type Bourns 3683S In precision design, linear; resolution: 0.1 %, accuracy: ±1.0 % (full scale), load capacity: 2.0 W at +25 °C (0 W at +85 °C), operating voltage: Max. 500 VAC, test voltage: 1000 VAC, tolerance: ±3.0 %, temperature range: 25 to +85 °C, temperature coefficient: ±100, mounting: Snap in. Type 10K
This text is machine translated.
This text is machine translated.
Scope of delivery
- 3683S-1-103L.
