Bresser Optik 5750900 Science TFM-301 Trino Transmission microscope Trinocular 1000 x Transmitted light
EAN:
Part number:
Item no:
Highlights & Details
Bresser Optik 5750900 Science TFM-301 Trino Transmission microscope Trinocular 1000 x Transmitted light
- Semi-plan lenses: 4x,10x,40x,100x (oil)
- WF 10x eyepieces with large field of view (20 mm)
- Köhler's lighting with integ. Illuminated panel aperture
- Coaxial object table adjustment
- Coaxial coarse and fine focusing
- Trinocular tube for connecting a C-mount camera
- Adjustable eye distance + diopter compensation (for both eyepieces)
- Long-life 3W LED lighting (adjustable)
Technical specifications
- Interpupillary distance min. (mm) 55
- Interpupillary distance max. (mm): 75
- Product type
Transmission microscope
- Type
Trinocular
- Optical magnification (min.)
40 x
- Optical magnification (max.)
1000 x
- Lighting type
Transmitted light
- Bulb type
LED (monochrome)
- Operating voltage
230 V / AC
- Factory colour
White
Black
- Dim
(L x W x H) 39 x 20.5 x 39.5 cm
- Length
39 cm
- Width
20.5 cm
- Height
39.5 cm
- Weight
6.34
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2188010 Bresser Optik 5750900 Science TFM-301 Trino Transmission microscope Trinocular 1000 x Transmitted light
User & Safety Instructions 2188010 Bresser Optik 5750900 Science TFM-301 Trino Transmission microscope Trinocular 1000 x Transmitted light
Description
THE NEW BRESSER Science TFM-301 microscope is equipped with semi-plan lenses.
The binocular insight enables a comfortable observation. The trinocular exit offers the possibility to connect a C-mount camera.
The WF 10x eyepieces have a field of vision of 20 mm and therefore offer a large field of view.
The eye distance can be adjusted from approx. 55 mm to approx. 75 mm. Diopter compensation is possible with both eyepieces.
The strong and long-lasting LED lighting can be controlled and is also very well suited for dark field microscopy*, among other things.
The voltage supply can be used flexibly: It can also be made via an existing USB connection using the power supply included in the delivery or with the enclosed cable.
The Köhler illumination can be adjusted with the permanently installed light field diaphragm and the height-adjustable and centered Abbe condenser (numerical aperture 1.25; with iris diaphragm). The condenser also has a print of the various magnifications, so the iris diaphragm can be adjusted quickly and precisely.
The coaxial shoots of the object table adjustment and the coarse and fine focusing enable an ergonomic working.
The trinocular extension allows the direct connection of a C-mount camera or MikroCam.
*with optional accessories
This text is machine translated.
The binocular insight enables a comfortable observation. The trinocular exit offers the possibility to connect a C-mount camera.
The WF 10x eyepieces have a field of vision of 20 mm and therefore offer a large field of view.
The eye distance can be adjusted from approx. 55 mm to approx. 75 mm. Diopter compensation is possible with both eyepieces.
The strong and long-lasting LED lighting can be controlled and is also very well suited for dark field microscopy*, among other things.
The voltage supply can be used flexibly: It can also be made via an existing USB connection using the power supply included in the delivery or with the enclosed cable.
The Köhler illumination can be adjusted with the permanently installed light field diaphragm and the height-adjustable and centered Abbe condenser (numerical aperture 1.25; with iris diaphragm). The condenser also has a print of the various magnifications, so the iris diaphragm can be adjusted quickly and precisely.
The coaxial shoots of the object table adjustment and the coarse and fine focusing enable an ergonomic working.
The trinocular extension allows the direct connection of a C-mount camera or MikroCam.
*with optional accessories
This text is machine translated.
Scope of delivery
- Microscope stand with integrated LED lighting
- Semi-plan lenses (4x, 10x, 40x, 100 x oil)
- Two pieces WF 10x eyepieces
- Immersion oil
- Dust cover
- Power supply (EU, GB) with USB power cable
- User manual
