Brumberg 18192000 RGBW controller 240 W 5 A 24 V dimmable
EAN:
Part number:
Item no:
Product type
RGBW controller
Power
240 W
Connection
Screw terminal
Output current (max.) - rounded
5 A
Output voltage (max.)
24 V
Datasheet (PDF)
Technical specifications
- Output power 120..240 W
- Dimming 1-10 V: no.
- Dimming DALI: no.
- DMX dimming: no.
- Phase section dimming: no.
- Dimming RF: no.
- Dimming Zigbee: no.
- Suitable for outdoor use: no.
- Suitable for direct voltage (primary side): Yes
- Suitable for constant voltage: Yes
- Suitable for constant current: no.
- Protection class III
- Type
dynamic
- Product type
RGBW controller
240 W
- LED features
dimmable
- Connection
Screw terminal
IP20
- Min. temperature
0 °C
- Max. temperature
+40 °C
- Dim
(L x W x H) 160 x 45 x 18 mm
- Max. output current
5 A
- Output current (max.) - rounded
5 A
- Height
18 mm
- Length
160 mm
- Width
45 mm
- Material (details)
Plastic housing
- Output voltage (max.)
24 V
- Output voltage (min.)
12 V
- Protection class
III
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2293741 Brumberg 18192000 RGBW controller 240 W 5 A 24 V dimmable
User & Safety Instructions
User & Safety Instructions 2293741 Brumberg 18192000 RGBW controller 240 W 5 A 24 V dimmable
Description
Wireless system controller for 1-4 channel operation. Wireless system controller universal for controlling 1-4 channel LED modules. Possible control variants: White light, TunableWhite, RGB, RGBW compatible with: Remote control White light: 18199000, 18202000, remote control TunableWhite: 18198000, 18201000, remote control RGB: 18197000, 18200000, remote control RGBW: 18196000, 18194070 or 18194080. Further functions for the above mentioned components can be found in the respective product description. Radio master controller 18192000: Voltage: 12-24 V DC, current: Max. 4 x 5 A, power: Max. 240 W / 480 W (12 V DC / 24 V DC), control: Negative (common anode), control signal: PWM, radio frequency: 869.5 MHz, range (line of sight): Up to 20 m, ambient temperature (ta): 0° C to +40° C, controller connection via screw terminals, dimensions: L 160 x W 45 x H 18 mm, material: Plastic, delivery: Incl. strain relief, controller per remote control: Max. 4 (with optimum wireless connection) Controller for system extension: 18195000 (wired): Voltage: 12-24 V DC, current: Max. 4 x 5 A, power: Max. 240 W / 480 W (12 V DC / 24 V DC), control: Negative (common anode), control signal: PWM, ambient temperature (ta): 0° C to +40° C, controller connection via screw terminals, dimensions: L 160 x W 45 x H 18 mm, material: Plastic, delivery: Incl. strain relief. Protection class: According to DIN EN 60529: IP20, Protection class: (EN 61140) III, Power: 120 to 240W, Type of dimming: Radio control,
