Image similar
Bürkert 0450 31711 2 up to 10 bar 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Nominal width 14 mm
- Line connection G 1/2 sleeve
- Special feature: Standard cable head
- Voltage 24 volt
- Frequency: Direct current
- Medium temperature (degree C) (max): 70
- Ambient temperature (degree C) (max): 70
- Ambient temperature (degree C) (min): -10
- Pressure (bar) (max): 10
- Medium temperature (degree C) (min): -10
- Operation: 5/2-way; output 2 pressurized in rest position
- Pressure (bar) (min): 2
- QNN VALUE (L/MIN): 3300
- Activation: Electromagnetic 32x32, spring reset
- Operating temperature
-10 °C (min)
- Min. operating temperature
-10 °C
- Manufacturer part #
31711
- Max. operating pressure
10 bar
- Operating pressure (min.)
2 bar
- Pressure range
2 up to 10 bar
- Pipe Ø
14 mm
- Type
450
- Max. ambient temperature
70 °C
- Min. ambient temperature
-10 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3046832 Bürkert 0450 31711 2 up to 10 bar 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3046832 Bürkert 0450 31711 2 up to 10 bar 1 pc(s)
