Image similar
Image similar
Bürkert Magnetic valve 42536 0312 24 V DC Flange Nominal width (details) 2 mm 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
3/2-way solenoid valve; direct action
- Compact design
- This text is machine translated.
Technical specifications
- Material: Brass
- Seal material NBR
- Nominal width 2 mm
- Line connection: Flange image: Bürkert KL-NR.001-01-06 (32x32)
- Special feature: Manual operation, PA rotation, rotary lever
- Voltage 24 volt
- Frequency: Direct current
- Missing attributes: Device socket type 2518 (00314802), without switching, 3-pin, 0-250 V AC/DC
- Medium temperature (degree C) (max): 90
- Ambient temperature (degree C) (max): 55
- Ambient temperature (degree C) (min): -10
- Pressure (bar) (max): 10
- Medium temperature (degree C) (min): -10
- 3/2-way; at rest output A de-energized
- Power consumption 8 watt
- QNN VALUE (L/MIN): 120
- Duty cycle (%): 100
- Opening time (msec) (max): 20
- Closing time (ms) (max): 22
- KV VALUE (M*3/H): 0.110
- Opening time (ms) (min): 15
- Closing time (ms) (min): 10
- Product type
Magnetic valve
- Operating voltage
24 V DC
- Max. operating pressure
10 bar
- Enclosure material
Brass
- Connection
Flange
- Media temperature (range)
-10 up to 90 °C
- Manufacturer part #
42536
- Sealant
NBR
- Function
3/2-way
- Max. media temperature
90 °C
- Media temperature (min.)
-10 °C
- Nominal width
2 mm
- QNn value
120 l/min
- Max. ambient temperature
55 °C
- Min. ambient temperature
-10 °C
- KV value
0.110 m³/h
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3047691 Bürkert Magnetic valve 42536 0312 24 V DC Flange Nominal width (details) 2 mm 1 pc(s)
Description
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
