Bürkert Process selector and control head 295568 8801 Enclosure material Stainless steel Sealant PTFE 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Drive - Drive design: PA drive, VA threaded bush on control air connection
- Drive - drive size: DM 125 mm
- Functions - Function: None specified
- Device properties - Drive type: Without valves
- Process/line connection - flange image: Interface element control and remote sensor to classic or third-party drive
- Voltage - Supply voltage: None
- Mode of action - control function: Closed with spring force
- Material: Stainless steel
- Seal material PTFE
- Nominal width 80 mm
- Line connection: Flange end according to DIN EN 1092-1 for DN80 (PN25) (old DIN 2634)
- Electronic. Lead-through connection
- Control: No signal
- Line connection 1: Not present
- Ways/positions: 2 ways / 2 positions
- Arm/drive interface: Nipple thread M100 x 2 (standard DN 80)
- Control air connection: Thread G1/4, socket
- Pneumatic function: Without valve
- Valve type: Straight seat valve type 2012
- Design: Without
- Distance sensor: Without
- Activation type: U repeater/pneumatic activation 8697
- Fluid connection: Without
- Operation/Config.: Without
- Proximity switch: 2 proximity switches, 2 conductor technology, 24 V DC
- Software repeater: None
- Additional function: None
- Communication: None
- Mounting: Without
- Operation: Not available
- Valve block VB1: Not equipped
- Control function VB1: No specification
- Valve block VB2: Not equipped
- Control function VB2: No information
- Approval system: Without approval
- Accessories: Without
- Approval Component: UL listed for USA and Canada cULus
- Product type
Process selector and control head
- Enclosure material
Stainless steel
- Connection
G 1/4 sleeve
- Manufacturer part #
295568
- Drive size Ø
125 mm
- Sealant
PTFE
- Medium
Compressed air
- Nominal width
80 mm
- Operating principle
OFF (spring shut)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3047820 Bürkert Process selector and control head 295568 8801 Enclosure material Stainless steel Sealant PTFE 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3047820 Bürkert Process selector and control head 295568 8801 Enclosure material Stainless steel Sealant PTFE 1 pc(s)
Description
The design of the Type 8801 On/Off ELEMENT system series allows easy integration of automation units in all levels: From the electrical/optical position feedback, the pneumatic control, an optionally integrated fieldbus interface up to the explosion-protected control head. The highly integrated system consisting of valve and automation unit is characterized by compactness and smooth surface in design, integrated control air ducts, degree of protection IP65/67/NEMA4X and high chemical resistance.
This text is machine translated.
This text is machine translated.
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
