Bürkert Socket 248156 2505 Number of pins: 2 0 - 50 V 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Electrical connection - Electrical connection Type: Wire strand
- Electrical connection - Electrical connection Line length: 1,000 mm
- Electrical connection - Electrical connection Number of contacts: 2
- Electrical connection - Electrical connection Polarity: Irrelevant
- Electrical connection - connector diagram: Rectangular plug type 2505, 8 x 4 mm
- Electrical connection - Device plug without wiring: Yes
- Electrical connection - Electrical connection Outlet: Straight
- Electrical connection - Electrical connection Wire cross-section (mm2): 0.14 mm²
- Electrical connection - Electrical connection Protective conductor: No.
- Device properties - Product sub-group: Device connector
- Device features - device plug connection LED: No.
- Device properties - device plug connection varistor: No.
- Device features - Device connectors Switching Rectifier: No.
- Device features - Device connectors Switching polar protection: No.
- Equipment characteristics - Device plug-in circuit protection snubber diode: No.
- Equipment characteristics - Device plug-in connection circuit redundant: No.
- Device features - Device connectors Wiring Kick and Drop-Electronics: No.
- Device features - Device connector Wiring Kick and Drop-Electronics with switching point detection: No.
- Device features - device plug connection Drop-off electronics: No.
- Device properties - device plug connection 3 to 2 conductor technology for impulse coils: No.
- Protection class IP rating (max. for suitable connection): IP30
- Voltage - voltage min. / nominal voltage: 0 V
- Voltage - voltage max. / nominal voltage 50 V
- Voltage - AC voltage: Yes
- Voltage - DC voltage: Yes
- Product type
Socket
- Min. operating voltage
0 V
- Max. operating voltage
50 V
- Manufacturer part #
248156
- Operating voltage
0 - 50 V
- Number of pins
2
- Number of contacts (details)
2
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3048054 Bürkert Socket 248156 2505 Number of pins: 2 0 - 50 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3048054 Bürkert Socket 248156 2505 Number of pins: 2 0 - 50 V 1 pc(s)
Description
Plug connector with latch for contacting Bürkert solenoid valves with square plug connection. This rugged and affordable plug connection is suitable for all Bürkert small solenoid valves
Analysis technology and process pneumatics established. In addition to flex and cable versions, connectors for PCB mounting are also available.
This text is machine translated.
Analysis technology and process pneumatics established. In addition to flex and cable versions, connectors for PCB mounting are also available.
This text is machine translated.
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
