Busch-Jaeger KNX 2TMA130050B0060 Console H8237-5B-03
EAN:
Part number:
Item no:
Technical specifications
- Height: 70 mm
- Width 230 mm
- Depth: 360 mm
- Mounting type: Surface-mounted
- Material: Other
- Colour, black
- Compatible with Apple HomeKit: No.
- Compatible with Google Assistant: No.
- Compatible with Amazon Alexa: No.
- IFTTT support available: No.
- Interface type: Other
- Screen size 254 mm (17")
- Screen size in inches: 10 inches
- Installation technology: Other
- Hearing aid compatible: Yes
- PTZ Function (Pan/Tilt/Zoom): No.
- Image system PAL
- Image system property: Color
- With video: Yes
- Bug-proof: Yes
- Smartphone connection possible: Yes
- Internal communication: Yes
- Hands-free: Yes
- With memory function: Yes
- Operation door opener: Yes
- Switching functions: Yes
- Function lamps: Yes
- With automatic door opener: Yes
- Call cut-off: Yes
- Call differentiation: Yes
- Additional unit can be stacked end-to-end: Yes
- Volume control: Yes
- With touch-screen: Yes
- Product type
Console
- Series
KNX
Manufacturer-specific
- Used at
Indoors
- Operating voltage
24 V DC
- Data transfer (Smart Home)
Wired
- Mounting type
Surface-mount
- Width
230 mm
- Height
70 mm
- Depth
360 mm
- Dim
(W x H x D) 230 x 70 x 360 mm
- Hub
Not required, optional for remote access
- Data exchange
Bidirectional (bi)
- Features
Touch function
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3551045 Busch-Jaeger KNX 2TMA130050B0060 Console H8237-5B-03
Description
Central control panel for Busch-Welcome® IP and optional Busch-free@home® or KNX.
For central control of up to 100 freely configurable KNX control elements. The programming is done by means of ETS DCA.
Functions of type: Switching, dimming, blinds, RTR, scene, Philips HUE
Note: KNX connection is performed by means of KNXnetIP tunneling. A KNX IP router or KNX IP interface is required in the system.
Alternatively, automatic display of all Busch-free@home® control frames with room structure.
An individual operator side with up to 18 freely configurable control frames.
Two dashboard pages with up to 12 control frames.
With integrated room temperature controller and temperature sensor.
Representation of the video image of the external station.
During the call, a picture of the visitor can be taken and stored in the image memory.
In case of door calls in absence, three images of the visitor are automatically saved in the picture memory.
Different ring tones can be set for door and floor calling.
Five polyphonic ringtones to choose from.
Individual ring tones (can be integrated via SD card)
Adjustable ring volume.
SD-card slot for extending the picture memory.
Equipped with an audio loop for connecting the audio signal to hearing aids.
Capacitive HD display with glass surface (resolution: 1280x800).
With hands-free function
Hands-free volume adjustable.
Individual audio absence function
For flush-mounting with 42361F-03.
Note : The LAN/LAN version cannot be installed on-wall
For integration in the myBUSCH-JAEGER portal.
Allows you to integrate tablets or smartphones with installed Busch-free@home® next APP or Busch-Welcome® APP as a mobile indoor location for audio and video communication.
Up to 4 mobile devices can be combined in each case.
Power supply via Power over Ethernet (PoE) 802.3af.
Alternative power supply via plug mains adapter 53011PS-03.
Rated current 600 mA (24 V DC).
Product line: Busch-free@home®, KNX, Busch-Welcome® IP
