Buy Camille Bauer SIRAX BT5100 Measuring converter for alternating voltage

Digital transducer display shows input as 500.0 volts and output as 0.00 milliamps. Three LEDs indicate status.

A digital transducer displaying an input of '500.0 V' and output of '040.0 mA'. Model: Sirax BT5100 by Camille Bauer.

1/2

Type

SIRAX BT5100

Configuration

Software

Input signal (voltage) (max.)

500 V

Input signal (voltage)

57…500 V L-L

Output (current)

0...20 mA / 4...20 mA

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Type: SIRAX BT5100

Configuration: Software

Input signal (voltage) (max.): 500 V

Input signal (voltage): 57…500 V L-L

Output (current): 0...20 mA / 4...20 mA

Output (voltage): 0...10 V

Operating voltage U(B): 24…60 V AC/DC

: DIN rail (top hat rail) 35 mm

: TRUE

: Other

: TRUE

: 50 Hz

: 500 V

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3532217 Camille Bauer SIRAX BT5100 Measuring converter for alternating voltage

Conformity certificate

Conformity certificate 3532217 Camille Bauer SIRAX BT5100 Measuring converter for alternating voltage

Description

Measuring converter for alternating voltage. The measuring transducer SIRAX BT5100 is a DIN rail device which is used to convert an AC input voltage into a DC current or voltage output signal proportional to the measured value. The AC input voltage and output current/voltage are shown on the display and shown on the Modbus interface. . Connection type single-phase (voltage) 2 configurable analog outputs linear or with bend in a range of 0/4…20 mA, 0/2…10 V Fast on-site programming by push buttons or via software Easy on-site device operation Clear and easy-to-read display of the measurement data via LCD display Flexible communication and remote reading via integrated Modbus-RTU interface DIN Rail rail mounting basic accuracy 0.2 %. Basic unit: With LCD display, DIN rail mounting Input range: AC 1P Voltage unfunctional Frequency range: 45-65 Hz Measurement input Current over current: Without measurement input Current over voltage: Without measurement input Voltage: 57…500 V L-L Auxiliary power: 24…10 V AC/DC Bus connection: RS485 (RTU) Standard protocol: Modbus Outputs: 20...0 mA / 4...0 mA or 20...60 V Measurement: Standard test protocol: With test protocol (only in English).
