Celduc SSR SON865040 50 A Switching voltage (max.): 480 V AC 1 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
6 V DC
Control voltage (max.)
32 V DC
Switching voltage (max.)
480 V AC
Current load (max.)
50 A
Datasheet (PDF)
Number
Minimum order quantity: 19
Multiple: 19
Total (€ 96.63 / piece)
€ 1,835.97
plus VAT.
Technical specifications
- Thyristor rated values: 50A
- Max. Switching current (A) 50A
- Function AC on/off Zero-Cross
- Relay type (AC or DC): AC
- Series: SON
- Heatsink included: No.
- Casing type: Hockey puck
- Standard
- Applications: (AC-1 / LC A) heating elements
- Number of switched phases: 1 phase
- Product type
SSR
- Type
SON865040
- Connection
Screws
- Control voltage (min.)
6 V DC
- Control voltage (max.)
32 V DC
- Control voltage range
6 - 32 V DC
- Control current (max.)
20 mA
- Surge current (max.)
750 A
- Switching voltage (min.)
50 V AC
- Switching voltage (max.)
480 V AC
- Current load (max.)
50 A
- Contact type
1 maker
- Min. temperature
-40 °C
- Max. temperature
+100 °C
- Content
1 pc(s)
- Mounting type
Screws
Documents & Downloads
Datasheet
Datasheet 3222067 Celduc SSR SON865040 50 A Switching voltage (max.): 480 V AC 1 pc(s)
Description
Cellduc SSR – SON865040
