CellPack 410358 EASY-PROTECT/522 Connector gel box flexible: 0.5-6 mm² fixed: 0.5-6 mm² Number of pins: 2 1 pc(s) Black
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Connector gel box
Cross section (flexible) (min.)
0.5 mm²
Cross section (flexible) (max.)
6 mm²
Cross section (inflexible) (min.)
0.5 mm²
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 11.76
3
6% = € 0.65
€ 11.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 11.76 / piece)
€ 11.76
plus VAT.
Only 3 Piece(s) available
Technical specifications
- Height dimensions 21.30 mm
- Housing type 5
- Housing number: 1 pieces
- Terminal number: 2 pieces
- Protection class: IPX8
- Polypropylene housing
- Latch: Latch
- Yellow color: Yellow translucent
- Gel material: Polyurethane
- Flammability class housing:V2
- Packaging type
Piece
- Product type
Connector gel box
- Cross section (flexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
6 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (inflexible) (max.)
6 mm²
- Number of pins
2
- Factory colour
Black
- Series
221
- Nominal current
32 A
- Nominal current - rounded value
32 A
- Content
1 pc(s)
- Dim
(L x W) 40.10 mm x 49.40 mm
- Manufacturer part #
410358
- Connection
Crimp
- Insulation material
Polypropylene
- Nominal voltage
450 V
- Width
49.40 mm
- Length
40.10 mm
- Connector clip features
PG
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3164796 CellPack 410358 EASY-PROTECT/522 Connector gel box flexible: 0.5-6 mm² fixed: 0.5-6 mm² Number of pins: 2 1 pc(s) Black
Security datasheet
Security datasheet 3164796 CellPack 410358 EASY-PROTECT/522 Connector gel box flexible: 0.5-6 mm² fixed: 0.5-6 mm² Number of pins: 2 1 pc(s) Black
Description
Yellow box with WAGO COMPACT connection terminals. Gel-filled casing for a simple, fast and safe moisture protection of WAGO COMPACT-connection terminals.
This text is machine translated.
This text is machine translated.
Features
- Protects the WAGO COMPACT connection terminal against moisture and water penetration according to IPX8
- VDE type-tested system according to EN 60998-2, approved with WAGO COMPACT connection terminals type 221
- Rigid, labeling and silicone-free gel
- UV-resistant, robust and accessible housing
- Fast, simple and safe mounting
- Ready to use
