Name: Chauvin Arnoux C.A 6011 Continuity tester Calibrated to (DAkkS standards) 200 Ω
Brand: Chauvin Arnoux
SKU: 2468696

Digital continuity testing meter with large blue display. Shows '0.35 Ω'. Buttons underneath for operation.

A person is inspecting a ventilation system using an electronic device connected with a green cable.

A hand is holding a voltage meter connected to a power socket. The display shows '123 V'.

A person is testing the electrical voltage of a socket using a measuring device. The display shows '0.3'.

A person is measuring the vibration of a drill with a digital measuring device. The display shows a value of 19.6 Hz.

Digital measuring device displays '0.75 Ω' on blue display, including control buttons and connection cable.

A digital device with a red display shows '2.53 Ω'. It has several control buttons and two connected cables.

A digital continuity measuring device displays the reading '0.35' on a blue screen. There are several function buttons underneath.

1/8

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Your handy continuity tester for daily use!

Large illuminated display (the largest on the market)
Clear and intuitive displays: Blue/red display, simple symbols, signal tone
Completely new functionality: Vibration function does not disturb the peace of your customers
Simple 4-button operation
High operating time: Up to 30,000 measurements!
High wearing comfort through shoulder strap and belt

Technical specifications

Product type: Continuity tester

Reading type: Resistance
Resistance

Continuity testing: 20 Ω

: DAkkS standards

Reading range - resistance: 1.0 Ω to 200.0 Ω

: IP40

Dim: (L x W x H) 13.5 x 22.5 x 18.5 cm

Weight: 350 g

Display type: Digital
Acoustic
Vibration

Insulation resistance (max.): 200 Ω

Reading category: CAT IV 300 V

Width: 22.5 cm

Height: 18.5 cm

Length: 13.5 cm

Documents & Downloads

Datasheet

Datasheet 2468696 Chauvin Arnoux C.A 6011 Continuity tester Calibrated to (DAkkS standards) 200 Ω

User & Safety Instructions

User & Safety Instructions 2468696 Chauvin Arnoux C.A 6011 Continuity tester Calibrated to (DAkkS standards) 200 Ω

Description

For the safety of electrical systems, the respective national laws prescribe a whole series of initial and recurring tests: Earthing measurement, insulation measurement, RCD testing, etc.…
Of all these checks, the systematic testing of the low resistance of the earth conductor is the most frequent (more than 80% of the test work).

The CA 6011 continuity tester has been specially developed to meet the needs of the user. It offers:
- clear indications: Clear colors and symbols for good/bad evaluation
- high operating comfort: Display unit can be removed, combination of shoulder strap and hip belt distribute the weight optimally with intensive use, elastic carrying strap at the display unit for attachment at the wrist for easy reading
- long battery life: Up to 30,000 measurements
- Switchable signal output: Acoustic or vibration for silent testing

This text is machine translated.
