Chauvin Arnoux Shunt Test current 10 A Voltage drop (num.) 100 mV Shunt resistor 10 A - 100mV
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 201.67 / piece)
€ 201.67
plus VAT.
14-day return policy included
Highlights & Details
Shunt resistor 10 A - 100mV
- Lab shunt resistor for measuring high DC currents with a voltmeter for the greatest possible safety
- Protective insulation in accordance with IEC 61010, CAT III 600 V
- Safety sockets and impact-resistant, self-extinguishing housing
- Accuracy class 0.5 and very small temperature coefficient
- For a short time, can be overloaded up to 20 A/200 mV
Technical specifications
- Product type
Shunt
- Test current
10 A
- Dim
(L x W x H) 95 x 55 x 152 mm
- Weight
420 g
- Reading category
CAT III 600 V
- Width
55 mm
- Height
152 mm
- Length
95 mm
- Voltage drop
100 mV
- Type
P01165223
Documents & Downloads
Datasheet
Datasheet 2793005 Chauvin Arnoux Shunt Test current 10 A Voltage drop (num.) 100 mV Shunt resistor 10 A - 100mV
User & Safety Instructions
User & Safety Instructions 2793005 Chauvin Arnoux Shunt Test current 10 A Voltage drop (num.) 100 mV Shunt resistor 10 A - 100mV
Warranty Terms
Warranty Terms 2793005 Chauvin Arnoux Shunt Test current 10 A Voltage drop (num.) 100 mV Shunt resistor 10 A - 100mV
Description
Lab shunt resistor for measuring high DC currents with a voltmeter for the greatest possible safety. Protectively insulated to IEC 61010, CAT III 600 V. Safety sockets and shock-resistant, self-extinguishing casing. Accuracy class 0.5 and very small temperature coefficient. For a short time, can be overloaded up to 20 A/200 mV.
