Chint 179733 NB1-63 4P B32 6kA DB Circuit breaker 4-pin 32 A 240 V, 415 V
EAN:
Part number:
Item no:
Product type
Circuit breaker
Number of pins
4
Release characteristics
B
Nominal current - rounded value
32 A
Nominal current
32 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 16.80
3
4% = € 0.75
€ 16.05
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 16.80 / piece)
€ 20.16
-17 %
€ 16.80
plus VAT.
Highlights & Details
LS SWITCH, 4POL B-CHAR. 32A 6KA
- Nominal voltage=240 V, 415 V
- Nominal current=32 A
- Switch-off capacity=6 kA
- Number of pins=4
Technical specifications
- Product type
Circuit breaker
- Number of pins
4
- Release characteristics
B
- Nominal current - rounded value
32 A
- Nominal current
32 A
- Factory colour
Blue
White
- Dim
(W x H x D) 72 x 86 x 78 mm
- Content
1 pc(s)
- Switch-off capacity
6 kA
- Insulation class
II
III
- Nominal voltage
240 V
415 V
- Width
72 mm
- Height
86 mm
- Depth
78 mm
Documents & Downloads
Datasheet
Datasheet 2525028 Chint 179733 NB1-63 4P B32 6kA DB Circuit breaker 4-pin 32 A 240 V, 415 V
User & Safety Instructions
User & Safety Instructions 2525028 Chint 179733 NB1-63 4P B32 6kA DB Circuit breaker 4-pin 32 A 240 V, 415 V
Warranty Terms
Warranty Terms 2525028 Chint 179733 NB1-63 4P B32 6kA DB Circuit breaker 4-pin 32 A 240 V, 415 V
Description
Protection of circuits against short circuit & overcurrent, also serves as a switch and insulator.
According to: IEC/EN: 60947-2
Short-circuit current on site must always be less than the switching capacity of the LS switch
This text is machine translated.
According to: IEC/EN: 60947-2
Short-circuit current on site must always be less than the switching capacity of the LS switch
This text is machine translated.
Scope of delivery
- LS SWITCH, 4POL B-CHAR. 32A 6KA
