Cimco Maxim 6 100736 Cable sheathing stripper 0.2 up to 6 mm² 9 up to 24 0.5 up to 3 mm
EAN:
Part number:
Item no:
Technical specifications
- Product type
Cable sheathing stripper
- Suitable for
PVC-coated cables
- Operating range (diameter)
0.5 up to 3 mm
- Working area diameter (min.)
0.5 mm
- Operating range (diameter) (max.)
3 mm
- Working area (cross section)
0.2 up to 6 mm²
- Working area cross section (min.)
0.2 mm²
- Operating range (cross section) (max.)
6 mm²
- Operating range (AWG diameter)
9 up to 24
- Operating range (AWG cross section) (min.)
24
- Operating range (AWG cross section) (max.)
9 awg
- Length stop range
4 up to 18 mm
- Length stop (min.)
4 mm
- Length stop (max.)
18 mm
- Length
290 mm
- Width
140 mm
- Weight
198 g
- Factory colour
Multicolour
- Depth
290.0000 mm
- Height
23.0000 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 809441 Cimco Maxim 6 100736 Cable sheathing stripper 0.2 up to 6 mm² 9 up to 24 0.5 up to 3 mm
Description
Automatic wire stripper MAXIM 6, for fine-stranded and solid conductors with PVC insulation, for round, oval and flat cable from 0.2 to 6 mm2. Stripping length with stop can be set to 4-18 mm for series work, no damage to the conductor by means of a special, self-calibrating, replaceable lamellae knife. Automatic opening of the jaws after stripping, built-in high-performance wire cutter.
