Circuit breakers Red, Yellow 3-pin 16 mm² 25 A 690 V AC Siemens
Item no:
Product type
Circuit breakers
Nominal voltage
690 V AC
Number of pins
3
Nominal current - rounded value
25 A
Operating voltage
690 V AC
Datasheet (PDF)
Technical specifications
- IP65 rating
- Isolation voltage: 690 V
- Operating frequency: 50/60 Hz
- Ambient temperature: -25 °C to +55 °C
- Surge voltage resistance: 6 kV
- Mechanical life: 100000
- Electrical life: 6000
- Color of the actuator: red
- Size of the switch disconnector: 2
- Power loss: 3.3 W
- Product type
Circuit breakers
- Operating voltage
690 V AC
- Nominal voltage
690 V AC
- Factory colour
Red
Yellow
- Cross section
16 mm²
- Number of pins
3
- Dim
(W x H x D) 67 x 79 x 349 mm
- Nominal current
25 A
- Nominal current - rounded value
25 A
- Type
Emergency stop switch
- Width
67 mm
- Height
79 mm
- Depth
349 mm
Documents & Downloads
Datasheet
Datasheet 1704885 Circuit breakers Red, Yellow 3-pin 16 mm² 25 A 690 V AC Siemens
User & Safety Instructions
User & Safety Instructions 1704885 Circuit breakers Red, Yellow 3-pin 16 mm² 25 A 690 V AC Siemens
Description
Coupling relay in industrial enclosure 2 change-over contacts combination voltage AC/DC 24 V and 110-120 V screw terminal
