Circuit breakers 1 breaker Siemens 3LD21641TB510AB1
EAN:
Part number:
Item no:
Product type
Circuit breakers
Number of pins
3
Contact type
1 breaker
Rated operation power at AC-3, 400 V
8 kW
Number of auxiliary contacts as normally open contact
1
Datasheet (PDF)
Technical specifications
- Product type
Circuit breakers
- Contact type
1 breaker
- Number of pins
3
8 kW
1
1
25 A
3
IP65
0
1
10 kW
0.64 kA
690 V
25 A
20
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2870096 Circuit breakers 1 breaker Siemens 3LD21641TB510AB1
User & Safety Instructions
User & Safety Instructions 2870096 Circuit breakers 1 breaker Siemens 3LD21641TB510AB1
Description
SENTRON, 3LD switch disconnectors, main switch, 3-pole, IU:25 A, Operating power / at AC-23 A at 400V: 9.5 kW, insulation material encapsulation for metric screw connection, 1NC, 1S, rotary drive, black, Including terminal covers for the supply side Main and emergency STOP switch SENTRON 3LD2 for the safe switching of loads in many ranges, e.g. for three-phase motors, air conditioning and ventilation systems, in loading and processing machines of machine and conveyor engineering, in the chemical or food and beverage industry.
Modular design, quick and easy fitting of auxiliary switches, N-PE terminal or 4. Pin Optimum mains separation from 16 A to 250 A by lockable the rotary drive. Protection class up to IP 65 with enclosed housing for outdoor applications. Versatile and worldwide usage thanks to international IEC, UL, CCC and shipbuilding approvals.
The 3LD main and emergency-OFF switches are available in a wide range of versions for front mounting, mounting plate, DIN rail or distributor installation, optionally with direct or door coupling rotary drive. With 3LD2, variants for DC applications are also available.
3LD main and emergency-OFF switch - consistent safety for users and systems.
This text is machine translated.
Modular design, quick and easy fitting of auxiliary switches, N-PE terminal or 4. Pin Optimum mains separation from 16 A to 250 A by lockable the rotary drive. Protection class up to IP 65 with enclosed housing for outdoor applications. Versatile and worldwide usage thanks to international IEC, UL, CCC and shipbuilding approvals.
The 3LD main and emergency-OFF switches are available in a wide range of versions for front mounting, mounting plate, DIN rail or distributor installation, optionally with direct or door coupling rotary drive. With 3LD2, variants for DC applications are also available.
3LD main and emergency-OFF switch - consistent safety for users and systems.
