Contact expansion PZE 9 24VDC 8n/o 1n/c PILZ Operating voltage: 24 V DC 8 makers, 1 breaker (W x H x D) 90 x 87 x 121 mm
EAN:
Part number:
Item no:
Product type
Contact expansion
Connector
Screw terminals
Operating voltage
24 V DC
Type
PZE 9 24VDC 8n/o 1n/c
Contact type
8 makers
1 breaker
Datasheet (PDF)
Technical specifications
- Application possibilities: Contact extension without delay
- Terminal type: Fixed
- Number of auxiliary contacts: 1
- Operating modes: Single-channel, two-channel, cross-circuit detection, without cross-circuit detection
- STANDARDS: EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1
- Number of safety contacts undelayed: 8
- Number of safety contacts delayed: 0
- Product type
Contact expansion
- Type
PZE 9 24VDC 8n/o 1n/c
- Connector
Screw terminals
- Operating voltage
24 V DC
- Contact type
8 makers
1 breaker
- Switching voltage (max.)
230 V AC
- Switching current (max.)
7.0 A
- Certification (sensors)
TÜV
- Operating temperature (min.)
-10 °C
- Operating temperature (max.)
+55 °C
- Depth
121 mm
- Width
90 mm
- Height
87 mm
- Dim
(W x H x D) 90 x 87 x 121 mm
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2182874 Contact expansion PZE 9 24VDC 8n/o 1n/c PILZ Operating voltage: 24 V DC 8 makers, 1 breaker (W x H x D) 90 x 87 x 121 mm
User & Safety Instructions
User & Safety Instructions 2182874 Contact expansion PZE 9 24VDC 8n/o 1n/c PILZ Operating voltage: 24 V DC 8 makers, 1 breaker (W x H x D) 90 x 87 x 121 mm
Description
Delayed and instantaneous contact extensions of the PNOZ X product family for contact reproduction and contact amplification. These serve as expansion devices for the safety contacts of a basic unit. Basic units are all safety switching devices or safety controls with feedback circuit monitoring. The product variants with off-delay can be identified by the V in the product designation, e.g. PZE X4VP.
