Buy Cotek DN 10-24 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W No. of outputs:1 x Content 1 pc(s)

Grey and orange electrical device with the label 'Cotek DN-10-24'. This is a direct current converter with input and output connections.

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

13 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 21.84 / piece)

€ 21.84

plus VAT.

Report legal concerns

Highlights & Details

Cotek DN 10-24 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W No. of outputs:1 x Content 1 pc(s)

Universal input voltage: 100 - 240 Vac, 124 - 370 V DC (single phase)
Output: 24V DC (adjustable +/- 10%) 0.42A 10W
LED DC OK indicator on unit
True DC OK signal output (5V)
Termination type: Screw terminals
3 year manufacturer warranty

Technical specifications

Type: DIN-rail mount

Nominal input voltage: 115 V/AC
230 V/AC
124 - 370 V/DC

Type: Switched Mode

Product type: Rail mounted PSU (DIN)

Min. input voltage: 88 V AC

Output voltage: 24 V DC

Input voltage: 100 - 240 Vac, 124 - 370 V DC

Input voltage (max.): 264 V AC

Max. output current: 0.42 A

Output current (max.) - rounded: 420 mA

: 10 W

Phases: 1

Output voltage (nominal): 24 V DC

No. of outputs: 1 x

Connection: Screw terminal

Dim: (W x H x D) 23 x 90 x 99 mm

Weight: 130 g

Output voltage (max.): 26.4 V DC

Output voltage (min.): 21.6 V DC

Manufacturer part #: DN 10-24

Content: 1 pc(s)

MTBF: 562700 h

Width: 23 mm

Height: 90 mm

Type: DN 10-24

Depth: 99 mm

: 10 W

Connections: Screw terminals

Output current (details): 0.42 A

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 513357 Cotek DN 10-24 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W No. of outputs:1 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 513357 Cotek DN 10-24 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W No. of outputs:1 x Content 1 pc(s)

Warranty Terms

Warranty Terms 513357 Cotek DN 10-24 Rail mounted PSU (DIN) 24 V DC 0.42 A 10 W No. of outputs:1 x Content 1 pc(s)

Description

At 23mm wide, Cotek's economical DN 10-24 miniature power supply saves space on DIN rails and offers a true DC OK signal output.

With an MTBF of 562700 h, the DN 10-24 offers high reliability and long life, and is covered by Cotek's 3 year manufacturer warranty. It is approved to EN60950-1 for ITE and UL508 for industrial applications and EN61000-3-2,-3 and Level B for conducted emissions.

Features

Short circuit, overload and over voltage protection
Standard DIN rail mounting
International use through wide-range input
Safety/reliability in accordance with CE, CSA, UL508, UL1310 Class 2, EMC/EMS EN55022 Class B, EN61000-3-2.3, EN55024, EN61000-4-2.3.4.5.6.8.11.
