Cougar CGR VG-650 PC power supply unit 650 W ATX 80 PLUS Bronze
EAN:
Part number:
Item no:
Product type
PC power supply unit
PSU output power
650 W
Modular
No
Certification
80 PLUS Bronze
Form factor
ATX
Highlights & Details
Cougar CGR VG-650 PC power supply unit
- Power supply unit output 650 W
- PCI-Express (6+2-Pin) 2x
- Cable management No
- 80 PLUS Bronze
Technical specifications
- Cooling: Active
- Number of fans: 1 fans
- CPU connector (4+4 pin): Yes
- PCI Express power connections (12+4-pin) Cable length 600 mm
- PCI Express power connections (12+4-pin) 1
- CPU power Cable length 70 cm
- SATA-power cable length 150.450 mm
- On/off switch: Yes
- AC input frequency 50/60 Hz
- Combined current (+3.3V) 130 W
- Combined current (+5Vsb): 15 W
- Combined current (+5V): 130 W
- Combined current (-12V): 3.6 W
- Combined current (+12V): 649.2 W
- Energy protection properties: Overcurrent, overload, overvoltage, overheating, short circuit, It provides total voltage
- Input current 10-6 A
- Power factor correction filter (PFC): Active
- Product type
PC power supply unit
- PSU output power
650 W
- Modular
No
- Certification
80 PLUS Bronze
- Form factor
ATX
- Factory colour
Black
- Dim
(W x H x D) 140 x 86 x 150 mm
- Depth
150 mm
- Height
86 mm
- Width
140 mm
- Weight
1.8 kg
- -12V / DC
0.3 A
- +12 V/DC (1)
54.1 A
- 5 V DC
20 A
- +5V / DC SB
3 A
- 24-pin
1
- 6-pin PCIe
2
- 5-pin SATA
6
- Features
ATX 3.1
- Power rating
501 - 750 W
- Fan size
120 mm
- 3.3V DC
20 A
- Operating voltage
100 - 240 V / AC
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3492132 Cougar CGR VG-650 PC power supply unit 650 W ATX 80 PLUS Bronze
Description
Cougar Gaming Cougar Power supply Atlas 650W ATX3.1 / 80 plus bronze. Total power 650 W, AC input voltage 100 240 V, AC input frequency 50/60 Hz Motherboard connector: 24-pin ATX, SATA power cable length 150.450 mm, PCI Express power connector (12+4-pin) Cable length 600 mm. Purpose: PC, power supply unit (PSU) Form factor: ATX, 80 Plus Certification: 80 PLUS Bronze. Product color: Black, cooling: Active, fan diameter: 12 cm.
