cudy CUDY Router
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Cudy Gigabit Multi-WAN VPN Router Quick Ethernet, Gigabit Ethernet gray
- Ethernet WAN
- IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
- Fast Ethernet, Gigabit Ethernet
- Web-based management
- DHCP Client DHCP Server
- 3DES, 128-bit AES, 192-bit AES, 256-bit AES, SHA-1, SHA-2, SHA-512
Technical specifications
- Internal memory type: DRAM
- Product type
Router
- Type
CUDY
- 10/100 Mbps ports
5 x
- 10/100/1000 Mbps ports
4 x
- 10/100/1000 Mbps WAN ports
5 x
- Width
119 mm
- Height
28 mm
- Depth
85 mm
- Weight
0.52
- Factory colour
Grey
- Material (details)
Metal
128 MB
- Safety
3DES
128-bit AES
192-bit AES
256-bit AES
SHA-1
SHA-2
SHA-512
- Transfer type
Corded
- UKCA
yes
- Operating temperature (T-T)
0 - 40 °C
- Storage relative humidity (H-H)
5 - 90 %
- Firewall
yes
- URL filtering
yes
- Universal Plug and Play (UPnP)
yes
- DSL WAN
no
- Ethernet WAN
yes
- SIM card slot
no
- 3G/4G USB modem compatibility
no
- MAC address filtering
yes
- Quality of Service (QoS) support
yes
- Static route
yes
- Policy-based routing
yes
- Web-based management
yes
- System event log
yes
- DHCP client
yes
- DHCP server
yes
- Reset button
yes
- SFP WAN
no
- WAN ports quantity
1
- WAN/Ethernet LAN ports quantity
3
- Quick installation guide
yes
- Full duplex
yes
- Flash memory
16 MB
- Concurrent connections
25000
- DMZ support
yes
- IP address filtering
yes
- Operating relative humidity (H-H)
10 - 90 %
- DoS attack prevention
yes
- Storage temperature (T-T)
-40 - 70 °C
Documents & Downloads
Datasheet
Datasheet 3798947 cudy CUDY Router
User & Safety Instructions
User & Safety Instructions 3798947 cudy CUDY Router
Description
Powerful VPN server and client
The R700 supports PPTP, L2TP, WireGuard, OpenVPN and IPsec protocols. You can use the dashboard to specify all or only specific clients for VPN usage. This allows you to force all traffic from the selected clients to meet more demanding security scenarios than a traditional proxy method.
Multi-WAN load balancing
The intelligent load balancing feature distributes data streams according to the bandwidth share of each WAN port to increase the utilization of multi-line broadband and enable a device to meet different Internet requirements.
Internet Access Management Strategy
Standardize users' online behavior and easily set employees' Internet access rights and strategies through IP/MAC/URL filtering and access control lists (ACL).
Flexible traffic control
Bandwidth control and session limitation enable administrators to flexibly manage network bandwidth and optimize usage.
Compact desktop design
Robust metal housing and design for table/wall mounting, suitable for different environments.
This text is machine translated.
Features
- 1× GbE WAN, 3× GbE WAN/LAN, 1× GbE LAN
- Load Balance or Link Backup Modes
- VPN, firewall, routing
Scope of delivery
- R700, power supply, Ethernet cable, installation guide
