cudy RE3000 RE3000 - 100 - 240 V - 0 - 40 °C - 10 - 90% Mesh network
EAN:
Part number:
Item no:
Datasheet (PDF)
Cudy RE3000 Network Expansion Module Network Repeater Black, Red 10, 100, 1000 Mbit/s.
Highlights & Details
- Network repeater 150 m 2402 Mbit/s
- WLAN Dual band (2.4 GHz/5 GHz) 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
- Black/red
Technical specifications
- Data transfer rate 2402 Mbit/s.
- WLAN standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
- Wi-Fi band Dual (2.4 GHz/5 GHz)
- Product type
Mesh network
- Type
RE3000 - 100 - 240 V - 0 - 40 °C - 10 - 90%
- Safety
WPA
WPA2
WPA2
- WPS compatible
Yes
- Width
129.6 mm
- Height
80 mm
- Depth
48.6 mm
- Factory colour
Black
Red
- Type
Network repeater
- No. of antennas
3 x
- 10/100/1000 Mbps ports
1 x
- Power supply (details)
100 - 240 V
- Weight
279 g
- Wi-Fi
Yes
- UKCA
yes
- Operating temperature (T-T)
0 - 50 °C
- Storage relative humidity (H-H)
5 - 90 %
- WLAN data transfer rate (first band)
574 Mbit/s
- WLAN data transfer rate (second band)
2402 Mbit/s
- Web-based management
yes
- Reset button
yes
- BeamForming
yes
- MU-MIMO technology
yes
- Operating relative humidity (H-H)
10 - 90 %
- Storage temperature (T-T)
-40 - 70 °C
- Maximum transfer distance
150 m
Documents & Downloads
Datasheet
Datasheet 3798894 cudy RE3000 RE3000 - 100 - 240 V - 0 - 40 °C - 10 - 90% Mesh network
User & Safety Instructions
User & Safety Instructions 3798894 cudy RE3000 RE3000 - 100 - 240 V - 0 - 40 °C - 10 - 90% Mesh network
Description
It is up to you to amplify or create a WLAN
Increase WLAN and share Ethernet
Convert an existing cable connection in WLAN
A range extender with a powerful AX3000 WiFi 6 and a Gigabit Ethernet connection. Press the WPS buttons to immediately expand the existing WLAN.
This text is machine translated.
Features
- Works with any WLAN router
- Dual band Wi-Fi 6
- 2402 Mbit/s + 574 Mbit/s WLAN 1
- 1× Gigabit Ethernet port
- 50 connected devices 2
- Cudy Mesh Satellite
- Multi-band simultaneous backhaul
- Ethernet backhaul
Scope of delivery
- Access Point, power supply, instructions
