Buy D-Link DGS-1530-20/E DGS-1530-20/E Network SFP+ switch

A D-Link network switch with 24 Ethernet ports and 4 uplink ports, used for connecting multiple devices in a local area network.

Fast track dispatch on Fri, 11 Sep

4 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 449.58 / piece)

€ 449.58

plus VAT.

Only 4 Piece(s) available

Report legal concerns

D-Link DGS-1530-20/E Network switch Managed L2 Gigabit Ethernet (10/100/1000), black

Highlights & Details

Managed L2 Web-based management
Quality of Service (QoS) Support Site Settings Configuration (CLI)
Number of basic switching RJ-45 Ethernet ports: 8 console port: RJ-45
10G support
MAC address table: 16000 entries Routing/switching capacity: 112 Gb/s.
Access control list
Rack mounting Stackable
AC

Technical specifications

Energy source: AC

Product type: Network SFP+ switch

LAN transfer rate: 10 MBit/s
100 MBit/s
1000 MBit/s

Working principle: Managed switch

Ethernet ports: 16

SFP+ ports: 4 x

SFP ports: 4 x

10/100/1000 Mbps ports: 16 x

Port type: 16 x 10/100/1000 + 4 x 10 Gigabit SFP+

Power supply (LOV): mains-powered

MAC addresses: 16000

Weight: 2 kg

Width: 280 mm

Height: 44 mm

Depth: 180 mm

Type: DGS-1530-20/E

Factory colour: Black

Max. ambient temperature: -5 °C

Min. ambient temperature: 50 °C

No. of USB A 2.0 ports: 1 x

Power supply (details): 100 - 240 V

Safety: SNMP
SNMPv2
SNMPv3

UKCA: yes

Operating temperature (T-T): -5 - 50 °C

Basic switching RJ-45 Ethernet ports quantity: 8

Packet buffer memory: 1.5 MB

Storage relative humidity (H-H): 0 - 95 %

Password protection: yes

Auto-negotiation: yes

Switching capacity: 112 Gbit/s

Heat dissipation: 89 BTU/h

Traffic classification: yes

Loop protection: yes

ARP inspection: yes

SFP+ module slots quantity: 2

Flow control support: yes

Power over Ethernet (PoE): no

MAC address filtering: yes

Quality of Service (QoS) support: yes

Port mirroring: yes

Link aggregation: yes

Stackable: yes

Jumbo frames support: yes

Multicast support: yes

Broadcast storm control: yes

Access Control List (ACL) ingress: 2000

Access Control List (ACL) egress: 1000

Policy-based routing: yes

Configuring Location Settings (CLI): yes

Web-based management: yes

Store-and-forward: yes

Access Control List (ACL): yes

USB Type-A ports quantity: 1

Rack mounting: yes

Mean time between failures (MTBF): 630098 h

Full duplex: yes

MAC address table: 16000 Eintragungen

SSH/SSL support: yes

IGMP snooping: yes

Auto MDI/MDI-X: yes

Number of VLANs: 4096

Spanning tree protocol: yes

Operating relative humidity (H-H): 0 - 95 %

VLAN support: yes

10G support: yes

Storage temperature (T-T): -20 - 70 °C

Forwarding rate: 83.33 Mpps

Power consumption (max): 25.7 W

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3466346 D-Link DGS-1530-20/E DGS-1530-20/E Network SFP+ switch

Description

The D-Link SmartPro DGS-1530-20 switch was developed in order to improve the network performance with a series of robust functions and specifications. With a capacity of up to 4,000 IPv4 routes and support for 8 IPv6 routes, this switch ensures efficient data processing in different network environments. With 20 ports, including 10/100/1000Base-T and 10 Gigabit SFP+ options, users can enjoy reliable connectivity and speed for larger networks.
This model operates in a temperature range from -5 °C to 50 °C and can therefore be adapted to different conditions while ensuring maximum operating time. The device supports a variety of management protocols such as SNMP and SSH for improved monitoring and configuration. Additional features such as RADIUS authentication and built-in fan-less design contribute to quieter operation, reduce noise exposure in office environments, and support sustainable practices.

This text is machine translated.
