D-Link DIS-N480-48 industrial power supply 480W external DIN rail
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
D-Link DIS-N480-48 power supply 480 W stainless steel
- 480W 48VDC DIN RAIL PSU
- Input 90 ~ 264Vac
- Output 48 ~ 55V DC
- DIN rail TS-35/7.5 or 15 mountable
- -20~70°C operating temperature
Technical specifications
- Product type
PSU
- Weight
1.493
- Width
85.5 mm
- Height
125.2 mm
- Depth
128.5 mm
- Type
DLink Deutschland
- Factory colour
Stainless steel
- PSU output power
480 W
- Power supply (details)
90 - 264 V
- Nominal load efficiency
92.5 %
- UKCA
yes
- Operating temperature (T-T)
-20 - 70 °C
- Storage relative humidity (H-H)
10 - 95 %
- Hold time
16 ms
- Rise time
100 ms
- Operating relative humidity (H-H)
20 - 95 %
- Power factor
0.98
- Storage temperature (T-T)
-40 - 85 °C
Documents & Downloads
Datasheet
Datasheet 3798283 D-Link DIS-N480-48 industrial power supply 480W external DIN rail
User & Safety Instructions
User & Safety Instructions 3798283 D-Link DIS-N480-48 industrial power supply 480W external DIN rail
Description
240W 48VDC DIN rail PSU 240W 48VDC ultra slim DIN rail PSU. Input 90 ~ 264Vac Output 48 ~ 55V DC. DIN rail TS-35/7.5 or 15 mountable. -20~70°C operating temperature. Compatible with DIS-100G, DIS-300G.
This text is machine translated.
Scope of delivery
- D-Link DIS-N480-48 industrial power supply 480W external DIN rail
