D-Link DMS-1024/E DMS-1024/E Network switch
EAN:
Part number:
Item no:
Highlights & Details
D-Link DMS-1024 unmanaged 2.5G Ethernet (100/1000/2500) black
- Unmanaged
- Quality of Service (QoS) support
- Number of basic switching RJ-45 Ethernet ports: 24
- MAC address table: 32000 entries Routing/switching capacity: 120 Gb/s.
- Stackable
- DC power supply included
Technical specifications
- Power source: Direct current
- Product type
Network switch
- Weight
3.42 kg
- Width
440 mm
- Height
44 mm
- Depth
250 mm
- Type
DMS-1024/E
- Factory colour
Black
- UKCA
yes
- Operating temperature (T-T)
-5 - 50 °C
- Basic switching RJ-45 Ethernet ports quantity
24
- Storage relative humidity (H-H)
0 - 95 %
- Switching capacity
120 Gbit/s
- Heat dissipation
62.29 BTU/h
- Traffic classification
yes
- Jumbo frames
12288
- Power over Ethernet (PoE)
no
- Quality of Service (QoS) support
yes
- Stackable
yes
- Jumbo frames support
yes
- Store-and-forward
yes
- Quick start guide
yes
- Mean time between failures (MTBF)
646913.55 h
- MAC address table
32000 Eintragungen
- Auto MDI/MDI-X
yes
- Operating relative humidity (H-H)
0 - 95 %
- 10G support
no
- Storage temperature (T-T)
-20 - 70 °C
- Forwarding rate
89.28 Mpps
- Power consumption (max)
35.489 W
- Power supply included
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3595708 D-Link DMS-1024/E DMS-1024/E Network switch
Description
The D-Link DMS-1024 is a powerful 24-port multi-gigabit unmanaged switch, Ideal for small offices, home offices and network edge environments. With 24 2.5 Gigabit ports it provides ultra-fast data transfer for modern devices such as Wi-Fi 6 access points or NAS.
The easy Plug & Play installation makes it immediately ready to use. Thanks to QoS, flow control and IGMP Snooping, network traffic is intelligently managed – Ideal for VoIP, streaming and IPTV. Green technology saves power while the long-lasting metal housing ensures reliable performance.
This text is machine translated.
The easy Plug & Play installation makes it immediately ready to use. Thanks to QoS, flow control and IGMP Snooping, network traffic is intelligently managed – Ideal for VoIP, streaming and IPTV. Green technology saves power while the long-lasting metal housing ensures reliable performance.
This text is machine translated.
Scope of delivery
- 24-port multi-gigabit unmanaged switch (DMS-1024), power cable, rack-mount kit, quick start guide
