D-Link Switch Power supply unit
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
D-Link DPS-520 PoE-adapter fast Ethernet, Gigabit Ethernet
- PSU output
- PCI Express (6+2-pin) x
- Cable management
Technical specifications
- Number of fans: 1 fans
- Product type
Power supply unit
- Dim
(W x H x D) 196 x 52 x 257 mm
- Weight
1.15 kg
- Width
196 mm
- Height
52 mm
- Depth
257 mm
- Factory colour
Black
- UKCA
yes
- Operating temperature (T-T)
0 - 50 °C
- Total Power over Ethernet (PoE) budget
180 W
- Storage relative humidity (H-H)
5 - 90 %
- Maximum operating distance
100 m
- Power over Ethernet (PoE) power per port
90 W
- Power over Ethernet (PoE)
yes
- Web-based management
yes
- Easy to install
yes
- Rack mounting
yes
- Operating relative humidity (H-H)
10 - 90 %
- Storage temperature (T-T)
-40 - 70 °C
- RJ-45 output ports
4
Documents & Downloads
Datasheet
Datasheet 3798284 D-Link Switch Power supply unit
User & Safety Instructions
User & Safety Instructions 3798284 D-Link Switch Power supply unit
Description
External redundant power supply - 180W PoE Total capacity 4 port Redundant power supply, 180 W Output power, max. 90 Watts per port, Universal external AC power supply for input voltages from 90-264VAC and 47-63Hz, Monitoring port, connection via Cat5e cable (PoE technology) up to 100m, standalone metal casing also for rack installation with opt. Mounting frame DPS-800, suitable for DGS-1520-28 and DGS-1520-52 (not for PoE models)
This text is machine translated.
Scope of delivery
- D-Link DPS-520 ext. Redundant power supply
