Danfoss 69810562 Fan heater devitemp 303 T Grey
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
- Robust constructionCorrosion-resistantMobile use or fixed installationSimple control, five-stage switching of the fanThermostat for setting the required temperature
Technical specifications
- Air flow 650 m³/hWith overheat protection: YesWith wheels: YesWith room thermostat: Yes
- Product type
Fan heater
- Operating voltage
230 V
3 kW
- Max. operating noise
35 dB
- Timer
Yes
- Heater features
Overheating protection
IPX4
- Protection class
IPX4
- Factory colour
Grey
- Dim
(L x W x H) 420 x 410 x 435 mm
- Weight
12 kg
- Feed length
1.5 m
n.rel.
- Width
410 mm
- Height
435 mm
- Length
420 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2600999 Danfoss 69810562 Fan heater devitemp 303 T Grey
User & Safety Instructions
User & Safety Instructions 2600999 Danfoss 69810562 Fan heater devitemp 303 T Grey
Description
Industrial fan heater, 21 kW, 400 V with timer. Suitable for stationary and mobile operation. The devices comply with the protection class IP X4 and can be used in dry and damp rooms.The power supply takes place via a fixed 1.5 m long connection cable H 07 RN-F4. Built-in continuous thermostat 0 to 40°C, safety thermostat, VDE approval, color gray RAL 7004n.Up to 24 hours delay start possible
