DEFENDER by Adam Hall Cable bridge 85150BLK Polyurethane Black No. of channels: 6 1010 mm Content: 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable bridge
Length
1010 mm
Use
Inside/outside
Load capacity
Bicycle
Pedestrian
Forklift
Pallet truck
Car
Wheelchair
Factory colour
Black
Highlights & Details
Defender NANO BLK Cable bridge 6 channels with black cover
- Black
- No. of channels: 6
Technical specifications
- Width channel 1 : 17 mmHeight of channel 1 : 18 mmWidth channel 2 : 17 mmHeight of channel 2 : 18 mmWidth channel 3 : 17 mmHeight of channel 3 : 19 mmWidth channel 4 : 17 mmHeight channel 4 : 19 mmWidth channel 5: 17 mmHeight of channel 5 : 18 mmWidth channel 6 : 17 mmHeight of channel 6 : 18 mmLoad capacity : Approx. 2t on an area of 20x20 cmChemical resistance: Petrol-resistant, short-term contact with solvents, oil-resistantHardness range : 88 ± 4 shoreFlame protection class : B2Temperature range : -30 to 60 °C.Weight: 4.7 kg.
- Product type
Cable bridge
- Factory colour
Black
- Length
1010 mm
- Use
Inside/outside
- Load capacity
Bicycle
Pedestrian
Forklift
Pallet truck
Car
Wheelchair
- Manufacturer part #
85150BLK
- Type
NANO BLK
- Dim
(L x W x H) 1010 x 285 x 32 mm
- Channels
6
- Assembly
Top
- Content
1 pc(s)
- Features
Movable top
Petrol-resistant
Oil-resistant
- Material
Polyurethane
- Width
285 mm
- Height
32 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2616395 DEFENDER by Adam Hall Cable bridge 85150BLK Polyurethane Black No. of channels: 6 1010 mm Content: 1 pc(s)
Description
6 narrow cable channels - discreet cable protection for indoor and outdoor useDefender® NANO-cable bridges are especially flat and can be easily crossed with a wheelchair. They are suitable for a wide range of indoor and outdoor applications and are available with both yellow and black lids. These cable bridges convince by 6 cable channels for a clean, orderly laying of cables, T-connectors as well as a load capacity of 2 tons on an area of 20 x 20 cm and enable the driving with light vehicles, trolley and - thanks to their flat profile - even forklift trucks and lifting wagons. Separately available end pieces (male/female) provide for a secure running in and out of the cable. Defender NANO cable bridges are used for carnival events, trade fairs, exhibitions, shopping centers and warehouses, as well as stages, studios and broadcasters. Not suitable for road traffic.
