Buy Degson DG240-2.54-10P-15-00AH-50 Spring-loaded terminal 0.51 mm² Number of pins 10 Orange 50 pc(s)

Orange terminal block with six slots and silver metal pins, for electrical connection.

Image similar

Product type

Spring-loaded terminal

2.54 mm

Pins per row

Number of pins

Connection

Spring-loaded terminal

Dispatches on Mon, 28 Sep

Sales and shipping:

Conrad Electronic Terms & Conditions

Packaging units

Number (Package size 50 pc(s))

Set(s)

Total (€ 1.65 / piece)

€ 82.34

plus VAT.

Report legal concerns

Highlights & Details

Spring-loaded terminal

Content 50 pc(s)

Our service for you

Technical specifications

Type: DG240-2.54-10P-15-00AH-50

Product type: Spring-loaded terminal

Features: + actuator

CS: 2.54 mm

No. of rows: 1

Pins per row: 10

Number of pins: 10

Series: DG240

Min. stripping length: 5 mm

Stripping length (max.): 6 mm

Connection: Spring-loaded terminal
Print

Nominal current: 4 A

Cross section (flexible) (min.): 0.08 mm²

Nominal current - rounded value: 4 A

Cross section (inflexible) (min.): 0.08 mm²

Cross section (flexible) (max.): 0.51 mm²

Cross section (inflexible) (max.): 0.51 mm²

AWG (min.): 28

Connector orientation: At an angle (to the PCB)

AWG max.: 20

Contact material: Phosphorus bronze tin plated

Enclosure material: Polyamide 6.6

Factory colour: Orange

Wire protection: Yes

Actuation direction: At an angle (to the PCB)

Weight: 4.15 g

Manufacturer part #: DG240-2.54-10P-15-00AH-50

Industrial packaging: Yes

Content: 50 pc(s)

Nominal voltage: 150 V

Width: 25.40 mm

Height: 20.89 mm

Length: 12.35 mm
