DEHN 766480 Inspection camera Probe length: 260 mm
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Colour, black
- Mounting type: Other
- Application area: Universal
- Nominal voltage (UN): 150 kV
- Frequency 15-60 Hz
- 12 megapixel resolution
- Video 4K/120fps
- Lens: Ultra wide angle (field of view 155°)
- Digital zoom 4 x
- 1/1.7" 4K CMOS sensor
- Image stabilizer: Electronic
- JPEG/RAW and MP4 formats
- Internal memory: 22 GB
- External SD memory card: MicroSD (max. 256 GB) *)
- Equipment: Remote control by APP
- Voice control: Yes
- Battery runtime: Max. 180 minutes
- Interfaces: USB type C.
- Housing dimensions 95 x 88 mm
- Total length of work head 260 mm
- Case dimensions 395 x 290 x 105 mm
- Product type
Inspection camera
- Probe length
260 mm
- Endoscope features
Wi-Fi
Digital zoom
Image function
Wireless transmission
Video output
SD card slot
- Digital zoom
4 x
- Field of view
155°
- Dim
(L x W x H) 95 x 62.4 x 67.8 mm
- Length
95 mm
- Width
62.4 mm
- Height
67.8 mm
- Type
766480
- Depth
33.3 mm
- Type
Standard (fixed)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3800278 DEHN 766480 Inspection camera Probe length: 260 mm
User & Safety Instructions
User & Safety Instructions 3800278 DEHN 766480 Inspection camera Probe length: 260 mm
Description
Wireless inspection camera for visual inspection and documentation of the condition of electrical systems up to 150 kV / 15 - 60 Hz. Simple control via APP - no activation of the system required!
