DEHN 952341 DG M TT ACI 275 FM Surge arrester Surge protection for: Switchboards 80 kA 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
DEHNguard® modular with dimensioning secure advanced circuit interruption
- In the protection module integrated ACI switch/radio links combination
- Ready-to-complete unit consisting of a base part and inserted protection modules
- High reliability through arrester monitoring" Thermodynamics-control" and ACI technology
Technical specifications
- Product type
Surge arrester
- Surge protection for
Switchboards
- Leakage current
80 kA
- Nominal voltage
230 V
400 V
- Pick-up time (details)
<100 ns
- Operating temperature
-40 °C - +80 °C
IP20
- Manufacturer part #
952341
- Type
2
- Dim
(W x H x D) 72 x 90 x 70 mm
- Width
72 mm
- Height
90 mm
- Depth
70 mm
- Content
1 pc(s)
DIN rail (top hat rail) 35 mm
IP20
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1968037 DEHN 952341 DG M TT ACI 275 FM Surge arrester Surge protection for: Switchboards 80 kA 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1968037 DEHN 952341 DG M TT ACI 275 FM Surge arrester Surge protection for: Switchboards 80 kA 1 pc(s)
Description
Multi-pole DEHNguard surge arresters, type 2 according to EN 61643 with integrated M ACI ACI switch/radio links combination, consisting of a base part and inserted protection modules. High reliability through arrester monitoring with thermodynamics-control. For the protection of low voltage consumer systems against the overvoltages. For use in lightning protection zones concept at the interfaces 0 B-1 and higher.
