Buy Dehner Elektronik EA 11012H-12 Bench PSU (fixed voltage) 12 V DC 10 A 120 W

A black power adapter with a long, thin cable and a plug at the end, suitable for electronic devices.

A black mains cable with a Europlug on one side and a three-pin IEC connector on the other.

1/2

Fast track dispatch on Wed, 30 Sep

26 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 53.77 / piece)

€ 53.77

plus VAT.

14-day return policy included

Report legal concerns

Highlights & Details

Desktop power supply EA 11012H-12 (12V/10A) Dehner Elektronik

Output voltage: 12 VDC
Output current (max.): 10A
Power: 120Watt
Output connector 2.1 x 5.5mm (center positive)
Protection class 2 (without protective conductor)
Efficiency – Level VI.
Overvoltage protection
Overload protection
Short-circuit protection

Technical specifications

Product type: Bench PSU (fixed voltage)

Used at: Indoors

Max. output current: 10 A

Output current (max.) - rounded: 10 A

Output: 5.5/2.1 coaxial connector

Output voltage: 12 V DC

Input voltage: 240 V AC

No. of outputs: 1 x

EuP Status: Step 2

Weight: 450 g

: 120 W

Type: Switched PSU

Width: 59 mm

Height: 34 mm

Length: 137 mm

Type: EA 11012H-12

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2159602 Dehner Elektronik EA 11012H-12 Bench PSU (fixed voltage) 12 V DC 10 A 120 W

Warranty Terms

Warranty Terms 2159602 Dehner Elektronik EA 11012H-12 Bench PSU (fixed voltage) 12 V DC 10 A 120 W

Description

Very powerful, compact power supply. Ideal as spare power supply for different applications. The power supply unit is suitable for continuous operation and offers a maximum of safety through the various protective measures. The power supply corresponds to the latest international energy saving guidelines

Due to the wide-range input from 100V/AC to 240V/AC, it is suitable for worldwide use. The output voltage is stabilised. The switched-mode power supply has a high degree of efficiency and thus a low heat generation.

This text is machine translated.
