Dehner Elektronik SPE 320-12 (12V 26.7A) SMPSU 12 V DC 26.7 A 320 W
EAN:
Part number:
Item no:
Highlights & Details
Built-in power supply SPE 320-12
- Output 12 V DC / 26.7 A
- Power 320 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
26.7 A
- Output current (max.) - rounded
26.7 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 212 x 115 x 30 mm
- Output voltage (max.)
12 V DC
- Connection
Screw terminal
320 W
- No. of outputs
1 x
- Type
closed
- Max. operating temperature (derating)
70 °C
- Weight
720 g
- PSU features
Regulated
- Width
115 mm
- Height
30 mm
- Length
212 mm
- Type
SPE 320-12 (12V 26.7A)
- MTBF
179000 h
- Output voltage (min.)
12 V DC
- PFC
Yes
- Max. temperature
85 °C
- Min. temperature
-40 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1783163 Dehner Elektronik SPE 320-12 (12V 26.7A) SMPSU 12 V DC 26.7 A 320 W
Warranty Terms
Warranty Terms 1783163 Dehner Elektronik SPE 320-12 (12V 26.7A) SMPSU 12 V DC 26.7 A 320 W
Description
With the SPE-series expands Sunpower its portfolio for the needs of the music, film and advertising industry and recording studios, music producers and artists. Further applications are applications for the acoustic irradiation of arenas, exhibition halls and large events, electronic devices for content creation and consumer electronics.
By the approved under the from 21. June 2019 applicable standard EN 62368-1, developers can the power supplies of the SPE-series for applications of various kinds future-proof. The low profile of only 30 mm makes it suitable for 1U rack.
The Standard IEC/EN 62368-1 summarizes the existing safety standards for IT applications (IEC/EN 60950-1) and for audio/video applications (IEC/EN 60065). The new standard deals with safety aspects for both IT and telecommunications applications as well as for audio and video applications.
This text is machine translated.
By the approved under the from 21. June 2019 applicable standard EN 62368-1, developers can the power supplies of the SPE-series for applications of various kinds future-proof. The low profile of only 30 mm makes it suitable for 1U rack.
The Standard IEC/EN 62368-1 summarizes the existing safety standards for IT applications (IEC/EN 60950-1) and for audio/video applications (IEC/EN 60065). The new standard deals with safety aspects for both IT and telecommunications applications as well as for audio and video applications.
This text is machine translated.
Features
- Screw clamp connection
- EN 62368-1.
Hints
Safety TUV, EN, UL, CSA, IEC EMC/EMS:
Safety UL 60950-1 2nd, CAN/CSA C22.2 No. 60950-1-07 2nd, UL 62368-1 (dated 2014-12-01), 2 nd Edition
IEC 60950-1:2005 + A1 + A2, IEC 62368-1:2014 (2nd Edition), TÜV EN 62368-1:2014 approved
