Dehner Elektronik SS 100-24VL LED transformer, LED driver Constant voltage 100 W 4.17 A 24 V DC Overvoltage, Surge prote
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 29.40
3
4% = € 1.27
€ 28.13
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 29.40 / piece)
€ 29.40
plus VAT.
Only 4 Piece(s) available
Highlights & Details
SS 100-24VL
- Constant voltage
- 24 V DC
- 4.17 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
- Operating current
4.17 A
- Dim
(L x W x H) 170 x 45 x 30 mm
- Factory colour
White
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Test mark
MM: SELV; TÜV; ; UKCA
- Max. output current
4.17 A
- Output current (max.) - rounded
4.17 A
- Operating voltage
240 V AC
- Protection class
IP20
- LED driver features
Overvoltage
Surge protection
Approved for use on furniture
IP20
- Connection
Screw terminal
- Max. power
100 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
4.17 A
- Input voltage (max.)
264 V AC
- Min. input voltage
180 V AC
- Weight
250 g
- Power (min.)
100 W
- Power range
100 up to 100 W
- Type
Switched PSU
- Width
45 mm
- Height
30 mm
- Length
170 mm
- Max. temperature
45 °C
- Min. temperature
-20 °C
Documents & Downloads
Datasheet
Datasheet 3015439 Dehner Elektronik SS 100-24VL LED transformer, LED driver Constant voltage 100 W 4.17 A 24 V DC Overvoltage, Surge prote
User & Safety Instructions
User & Safety Instructions 3015439 Dehner Elektronik SS 100-24VL LED transformer, LED driver Constant voltage 100 W 4.17 A 24 V DC Overvoltage, Surge prote
Warranty Terms
Warranty Terms 3015439 Dehner Elektronik SS 100-24VL LED transformer, LED driver Constant voltage 100 W 4.17 A 24 V DC Overvoltage, Surge prote
Description
Power supply specially designed for LED lighting, especially compact and inconspicuous design. Suitable for various LED applications in the interior (e.g. decoration, furniture installation, suspended ceilings).
This text is machine translated.
This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
