Deko Light 565431 Downlight - Anik Square 90 Flush mount light LED (monochrome) 9 W Traffic white (RAL 9016)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Deco Light Downlight - Antique Square 90, 9 W, DIM, 3000 K, white
- Power= 9 W Total luminous flux= 1050 lm Colour temperature= 3000 K Warm white
Technical specifications
- Operating mode: Current constant
- Colour consistency 3 SDCM
- Switching cycles 100000
- Rated current 260 mA
- Input voltage 32-37 V/DC
- UGR 19
- Product type
Flush mount light
- Operating voltage
37 V DC
- Bulb type
LED (monochrome)
9 W
- Total luminous flux
1050 lm
3000 K
- Colour
Warm white
- Energy consumption
9 kWh/1000h
- Type
Rectangular
- Radiation angle
120°
- Light features
Dimmable
- Recess length
94 mm
- Recess width
94 mm
- Recess depth
17.5 mm
IP44
IP20
IK05
- Protection class
III
- Factory colour
Traffic white (RAL 9016)
- Material
PMMA
Steel
Aluminium
- Weight
155 g
n.rel.
- Dim
(L x W x H) 110 x 110 x 20.5 mm
Yes
- Light bulb included
Yes
- Colour temperature range
3000 K
- Width
110 mm
- Height
20.5 mm
- Length
110 mm
Documents & Downloads
Datasheet
Datasheet 3766321 Deko Light 565431 Downlight - Anik Square 90 Flush mount light LED (monochrome) 9 W Traffic white (RAL 9016)
User & Safety Instructions
User & Safety Instructions 3766321 Deko Light 565431 Downlight - Anik Square 90 Flush mount light LED (monochrome) 9 W Traffic white (RAL 9016)
Warranty Terms
Warranty Terms 3766321 Deko Light 565431 Downlight - Anik Square 90 Flush mount light LED (monochrome) 9 W Traffic white (RAL 9016)
Description
The LED downlight ANIK SQUARE is a high quality light solution for a wide range of applications such as reception areas, offices, conference rooms, shops, retail areas, Hotels, restaurants, bathrooms and toilets. It impresses through a uniform, wide-spread light distribution with an angle of radiation of 120° and a very high color reproduction (Ra ≥ 90). Thanks to the protection class IP44 on the bottom in the installed state, it is also suitable for moist surroundings. The lamp can be combined with external power supplies and thus can be dimmed. The ANIK ROUND series covers a wide power spectrum from 9 W to 30 W and is available in 2700 K, 3000 K and 4000 K color temperatures. With its flat design (19–22 mm height) and various diameters (144–398 mm), it is suitable for both new buildings and renovation projects.
