Dell USB-C® docking station Pro SD25TB5
EAN:
Part number:
Item no:
Dell DELL-SD25TB5 USB-C® docking station
Highlights & Details
- Connection A (or inputs): USB-C®
- Connecton B (or outputs): HDMI®, USB 3.2 2nd Gen (USB 3.1), 4x USB-C®, LAN (10/100/1000 Mbps), DisplayPort
- No. of supported monitors:
- Maximum resolution:
- Key features:
Technical specifications
- Host Interface: Thunderbolt 5
- HDMI version 2.1
- Data transfer rate 1.25 Gbps
- Other operating systems support: ChromeOS
- Product type
USB-C® docking station
- Type A
USB-C®
- Type B
HDMI®
USB 3.2 2nd Gen (USB 3.1)
4x USB-C®
LAN (10/100/1000 Mbps)
DisplayPort
- Interfaces
1x HDMI
2x DisplayPort
LAN
4x USB 3.2 2nd Gen (USB 3.1)
4x USB-C®
- Cable length
0 cm
- Factory colour
Black
- Width
90 mm
- Height
205 mm
- Depth
35.3 mm
- Weight
632 g
- Dim
(W x H x D) 90 x 205 x 35.3 mm
- Frame rate
120 Hz
- No. of DisplayPort
2 x
- No. of HDMI ports
1 x
- No of. USB type A 3.1 /3.2 2nd gen
4 x
- Keyboard layout
English, QWERTY
- 10/100/1000 Mbps ports
1 x
- PSU power
330 W
- Transfer type
Corded
- UKCA
yes
- AC adapter included
yes
- Ethernet LAN
yes
- Cable lock slot
yes
- Quantity per pack
1 Stück(e)
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
- Microphone in
no
- DC-in jack
yes
- Wake-on-LAN ready
yes
- USB Type-C DisplayPort Alternate Mode
yes
- Card reader integrated
no
- USB Power Delivery up to
15 W
- Quick start guide
yes
- Thunderbolt 5 ports quantity
2
- Maximum digital resolution
3840 x 2160 p
- Number of storage drives supported
4
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3474535 Dell USB-C® docking station Pro SD25TB5
Description
Handle large workloads with the versatile, intelligent Thunderbolt 5 docking station with up to 300-watt future-ready performance and remote management capabilities.
