Delock 63953 GBIC [1x U.2, SATA - 1x M2]
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
U.2 SFF-8654 or SATA converter to 1 x M.2 Key M Slot
- built-in
- Host Interface: M.2
- Output interface: SAS, SATA
- NVMe SSD
Technical specifications
- Product type
GBIC
- Connection type
SATA
M.2 NGFF
- No. of A connectors
1 x
- Type A
U.2
SATA
- No. of B connections
1 x
- Type B
M2
- Compatible with
22110
2280
2260
2242
2230
SATA SSD
- Cable design
Round
- Version
Cable
- Factory colour
Multicolour
- Depth
51 mm
- Height
9 mm
- Width
145 mm
- Cable use
C13/C14 appliances
- Weight
110 g
- UKCA
yes
- Quantity
1
- Number of M.2 (M) slots
1
- Internal
yes
- NVMe
yes
- Manual
yes
Documents & Downloads
Datasheet
Datasheet 3380132 Delock 63953 GBIC [1x U.2, SATA - 1x M2]
User & Safety Instructions
User & Safety Instructions 3380132 Delock 63953 GBIC [1x U.2, SATA - 1x M2]
Description
An M.2 SSD in 22110, 2280, 2260, 2242 and 2230 format can be connected to this Delock converter. It enables the use of an M.2 SSD on PCIe or SATA basis. The converter can be integrated internally via the SATA interface in the system, when using a SATA M.2 SSD, or via the U.2 interface, when using a PCIe M.2 SSD.
This text is machine translated.
This text is machine translated.
Features
- Connections:
- 1 x 38 pin SFF-8654 4i socket (for PCIe SSDs)
- 1 x SATA 6 GB/s 22-pin plug (for SATA SSDs)
- 1 x 67 Pin M.2 Key M Slot
- Interface PCIe / SATA
- Supports M.2 modules in the format 22110, 2280, 2260, 2242 and 2230 with
- Key M or Key B+M on SATA basis or PCIe basis
- Maximum height of the components on the module: 1.5 mm,
- Use of modules equipped on two sides possible
- LEDs for Power and activity
- Bootable
- Supports NVM Express (NVMe SSD)
- Maximum output current 4 A.
- Short-circuit protection, overheating protection
- ESD protection up to 2 kV
- Dim. (LxWxH): Approx. 145 x 51 x 9 mm
System requirements
- Linux Kernel 3.19 or later
Windows 7/7-64/8.1/8.1-64/10/10-64
A free U.2 SFF-8643 interface (PCIe SSD) or
A free SATA 22-pin interface (SATA SSD)
