Delock 66454 HDMI switch 3840 x 2160 p
EAN:
Part number:
Item no:
Datasheet (PDF)
HDMI Matrix Switch 4 x HDMI in to 2 x HDMI out 4K 60 Hz with audio extractor
Highlights & Details
- HDMI video port type
- 3840 x 2160 pixels
- Black
- 1 pieces(s)
Technical specifications
- Product type
HDMI switch
- Supported monitors
2
- Resolution (max.)
3840 x 2160 p
- Factory colour
Black
- Width
10.5 cm
- Height
2 cm
- Depth
25 cm
- Weight
0.961
- Cable design
Round
- Version
Cable
- Display resolution
3840 x 2160 Pixel
- Frame rate
60 Hz
- No. of HDMI ports
6 x
- Cable use
C13/C14 appliances
- HDR support
Yes
- Material
Metal
- UKCA
yes
- AC adapter included
yes
- Remote control included
yes
- AC adapter input current
0.3 A
- Quantity per pack
1 Stück(e)
- 3.5 mm (1/8-inch) out
yes
- DC-in jack
yes
- Digital audio optical out
1
- Extended display identification data (EDID)
yes
- Manual
yes
- Bandwidth
600 MHz
- HDCP
yes
- HDMI in
4
- Number of HDMI outputs
2
- Mounting brackets included
yes
- AC adapter output current
1 A
- Power consumption (max)
4 W
Documents & Downloads
Datasheet
Datasheet 3384139 Delock 66454 HDMI switch 3840 x 2160 p
User & Safety Instructions
User & Safety Instructions 3384139 Delock 66454 HDMI switch 3840 x 2160 p
Description
This HDMI switch from Delock can be used to operate up to four HDMI devices on two HDMI monitors, TVs or projectors. You can switch between the HDMI devices using the button on the device or the remote control.
Matrix switch
Every input can be switched to every output; in this way, the desired source can be selected for each monitor. This also enables parallel output of a source to two monitors.
Downscaler
If a monitor does not support high resolution, the built-in downscaler can scale the image from 4K to 1080p.
Audio Extractor
This function can be used to uncouple the audio signal from a HDMI transmission. While the image signal is displayed on a TV or monitor, the audio signal can be output digitally (S/PDIF) or analogue (stereo) to other devices such as headphones or surround receiver.
Audio return channel (ARC)
ARC can be activated on the device or on the remote control at the push of a button. The audio signal of the connected TV set is then output at the S/PDIF connectors of the switch.
This text is machine translated.
Matrix switch
Every input can be switched to every output; in this way, the desired source can be selected for each monitor. This also enables parallel output of a source to two monitors.
Downscaler
If a monitor does not support high resolution, the built-in downscaler can scale the image from 4K to 1080p.
Audio Extractor
This function can be used to uncouple the audio signal from a HDMI transmission. While the image signal is displayed on a TV or monitor, the audio signal can be output digitally (S/PDIF) or analogue (stereo) to other devices such as headphones or surround receiver.
Audio return channel (ARC)
ARC can be activated on the device or on the remote control at the push of a button. The audio signal of the connected TV set is then output at the S/PDIF connectors of the switch.
This text is machine translated.
Features
- Connections:
- Input:
- 4 x HDMI-A socket
- 1 x DC 12 V power connection can be screwed on
- Output:
- 2 x HDMI-A socket
- 1 x 3.5 mm 3 pin jack socket (audio)
- 1 x TOSLINK jack S/PDIF
- HDMI port switching: Automatic, button or infrared remote control
- LED displays for active HDMI connection
- High Speed HDMI specification
- Supports 3D Displays
- Supports HDCP 1.4 and 2.2
- Supports HDR
- Supports EDID management
- Supports ARC (Audio Return Channel)
- Resolution up to 3840 x 2160 @ 60 Hz (depending on the system and the connected hardware)
- Video bandwidth up to 600 MHz / 6 Gbps, max. 18 Gbps
- Power consumption: max. 4 W
- Metal housing
- Removable wall mount
- Colour, black
- Dim. (LxWxH): Approx. 251 x 105 x 20 mm
System requirements
- A free HDMI socket
HDMI cable
