Delock 88396 88396 Wi-Fi antenna 5 dBi 2.4 GHz
EAN:
Part number:
Item no:
Delock 88396 Network-Antenna 5 dBi
Highlights & Details
- 5 dBi
- 2.4 GHz
- 50 Ohm
Technical specifications
- Impedance: 50 ohm
- Product type
Wi-Fi antenna
- Gain
5 dBi
- Type
Monopole antenna
- Wi-Fi frequency band
2.4 GHz
- Antenna socket
RPSMA plug
- Antenna socket
RP-SMA plug
- Weight
0.10
- No. of ports
1
- Polarisation
Linear
Vertical
- Width
13.20 mm
- Height
165 mm
- Length
200.30 mm
- Version
Adapter
- Factory colour
Multicolour
- Depth
12.5 mm
- Charging capacity (max.)
7.5 W
- Charging capacity (min.)
2.5 W
- UKCA
yes
- Operating temperature (T-T)
-20 - 65 °C
- Storage temperature (T-T)
-30 - 75 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3380359 Delock 88396 88396 Wi-Fi antenna 5 dBi 2.4 GHz
Description
You can connect this wireless LAN antenna to your WLAN device with SMA connection in order to receive a signal.
This text is machine translated.
This text is machine translated.
Features
- RP-SMA plug connections
- Frequency range 2.400 - 2.500 GHz
- Antenna gain 5 dBi
- Impedance: 50 ohm
- Polarisation: linear, vertical
- VSWR: ≤2.0
- Operating temperature: -10 °C ~ 55 °C
- ABS casing material
- Colour, black
- Length:
- Approx. 200.30 mm (with articulated joint)
- Approx. 167.80 mm (without swivel joint)
- Diameter:
- Approx. 6.00 mm (tip)
- Approx. 13.20 mm (RP-SMA)
System requirements
- Device with a free RP-SMA socket
