Delock 88879 Internal antenna GSM
EAN:
Part number:
Item no:
GSM / UMTS antenna SMA plug 3 dBi omnidirectional rigid with magnetic base black
Highlights & Details
Technical specifications
- Product type
Mobile phone antenna
- Mobile phone standard
GSM
UMTS
- Factory colour
Black
- Gain
3 dBi
- Antenna type
Internal antenna
- Suitable for mains
GSM
- Width
3 cm
- Height
25 cm
- Cable length
2 m
- Version
Adapter
- Depth
30 mm
- Cable use
Networks
- Charging capacity (max.)
7.5 W
- Charging capacity (min.)
2.5 W
- Weight
0.10
- UKCA
yes
- Operating temperature (T-T)
-10 - 75 °C
- Antenna gain level (max)
3 dBi
- Impedance
50 Ohm
- Quantity per pack
1 Stück(e)
- Diameter
3 cm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3380582 Delock 88879 Internal antenna GSM
Description
This Delock antenna allows the use of the GSM / UMTS bands indoors and outdoors.
This text is machine translated.
This text is machine translated.
Features
- Connection: SMA plug
- Frequency range:
- 824 - 960 MHz
- 1,920 - 2,170 MHz
- Antenna gain 3 dBi
- Impedance: 50 ohm
- VSWR: ≤2.0
- Polarisation: linear, vertical
- Operating temperature 10 °C - 75 °C
- Cable color: Black
- Cable type: RG-174
- Cable length incl. connections: Approx. 2 m.
- Antenna length: Approx. 21.5 cm
- Antenna length incl. magnetic base: Approx. 25 cm
- Diameter of magnetic base: Approx. 3 cm
System requirements
- Device with a free SMA socket
