Delock 89437 89437 Wi-Fi antenna 2 dBi 2.4 GHz
EAN:
Part number:
Item no:
Delock 89437 Network-Antenna Omni-directional Antenna SMA 2 dBi
Highlights & Details
- Omni-directional antenna SMA
- 2 dBi
- 2.4 - 2.4835 / 5.15 - 5.7250 GHz
- 50 Ohm
Technical specifications
- Frequency range 2.4 - 2.4835 / 5.15 - 5.7250 GHz
- Impedance: 50 ohm
- Product type
Wi-Fi antenna
- Gain
2 dBi
- Type
Monopole antenna
- Wi-Fi frequency band
2.4 GHz
- Antenna socket
SMA plug
- Weight
0.10
- No. of ports
1
- Polarisation
Linear
Vertical
- Width
108 mm
- Factory colour
Black
- UKCA
yes
- Operating temperature (T-T)
-20 - 65 °C
- Diameter
1 cm
- Antenna gain (2.4 GHz)
2.5 dBi
- Antenna gain (5 GHz)
5.7 dBi
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3380685 Delock 89437 89437 Wi-Fi antenna 2 dBi 2.4 GHz
Description
You can connect this WLAN antenna to your WLAN device with SMA connection in order to receive and send signals.
- Connection: SMA connector
- With tilt joint, rotatable
- Frequency range: 2.4000 ~ 2.4835 GHz,
5.1500 ~ 5.7250 GHz
- Antenna gain: 1.5 dBi @ 2.5 GHz
2.1 dBi @ 5.7 GHz
Impedance: 50 ohm
- VSWR: 2.0 max.
- Operating temperature: -20 °C ~ 65 °C.
- Length with tilting joint approx. 108 mm, without tilting joint approx. 82.5 mm
- Diameter: 7.8 mm (Ø tip)
10.0 mm (Ø SMA)
This text is machine translated.
- Connection: SMA connector
- With tilt joint, rotatable
- Frequency range: 2.4000 ~ 2.4835 GHz,
5.1500 ~ 5.7250 GHz
- Antenna gain: 1.5 dBi @ 2.5 GHz
2.1 dBi @ 5.7 GHz
Impedance: 50 ohm
- VSWR: 2.0 max.
- Operating temperature: -20 °C ~ 65 °C.
- Length with tilting joint approx. 108 mm, without tilting joint approx. 82.5 mm
- Diameter: 7.8 mm (Ø tip)
10.0 mm (Ø SMA)
This text is machine translated.
Features
- SMA plug connections
- Frequency range:
- 2.400 - 2.500 GHz
- 5.150 - 5.875 GHz
- Antenna gain 2 dBi
- Impedance: 50 ohm
- Polarisation: linear, vertical
- VSWR: ≤2.0
- Operating temperature: -10 °C ~ 55 °C
- ABS casing material
- Colour, black
- Length:
- Approx. 111.70 mm (with articulated joint)
- Approx. 83.40 mm (without swivel joint)
- Diameter:
- Approx. 7.80 mm (tip)
- Approx. 10.00 mm (SMA)
System requirements
- Device with a free SMA socket
